Chapter 1 Cisco NAC Appliance Hardware Platforms
Rear Panel Features
Figure 1-22
14
1
2
3
4
5
6
7
Figure 1-23
1
2
3
4
5
6
OL-20326-01
Cisco NAC-3350 Rear Panel
1 2
13 12 11 10 9
NIC 3 (eth2) PCI-X port (Intel)
NIC 4 (eth3) PCI-X port (Intel)
PCI Express expansion slot 2
Power supply bay 1
Power supply bay 2
Integrated NIC 2 (eth1) port (Broadcom)
Integrated NIC 1 (eth0) port (Broadcom)
Cisco NAC-3350 Rear Panel LEDs
1 2 7
4 6
3 5
iLO 2 NIC activity LED
iLO 2 NIC link LED
10/100/1000 NIC 3 (Intel) Activity
LED
10/100/1000 NIC 3 (Intel) Link LED
10/100/1000 NIC 4 (Intel) Activity
LED
10/100/1000 NIC 4 (Intel) Link LED
3 4
8 7 6
8
Keyboard connector (purple)
9
Mouse connector (green)
10
Video connector (blue)
11
Serial connector
12
USB connector
13
USB connector
14
iLO 2 NIC connector (RJ-45)
8 9 10 11 12 13
Green = Activity exists
Flashing green = Activity exists
Off = No activity exists
Green = Link exists
Off = No link exists
Steady green = High activity
Flashing green = Activity exists
Off = No activity (if link LED is off, link is dead)
Orange = 1000 Mbps
Green = 100 Mbps
Off = 10 Mbps (if activity LED is off, link is dead)
Steady green = High activity
Flashing green = Activity exists
Off = No activity (if link LED is off, link is dead)
Orange = 1000 Mbps
Green = 100 Mbps
Off = 10 Mbps (if activity LED is off, link is dead)
Cisco NAC Appliance Hardware Installation Guide
NAC-3310, NAC-3350, and NAC-3390
