Chapter 1 Cisco NAC Appliance Hardware Platforms

Front Panel Features

Figure 1-24
1
2
3
4
Figure 1-25
1
2
3
OL-20326-01
Cisco NAC-3390 Front Panel
1 2
Hard drive bay 1
Hard drive bay 2
Hard drive bay 3
Hard drive bay 4
Cisco NAC-3390 Front Panel LEDs /Buttons
Power On/Standby button
and system power LED
UID button/LED
Internal health LED
5
3 4
5
CD-ROM/DVD drive
6
Video connector
7
HP Systems Insight Display
8
USB connector
1 2
Green = System is on
Amber = System is shut down, but power is still applied
Off = Power cord is not attached, power supply failure has
occurred, no power supplies are installed; facility power is not
available, or disconnected power button cable
Blue = Identification is activated
Flashing blue = System is being managed remotely
Off = Identification is deactivated
Green = System health is normal
Amber = System health is degraded. (To identify the component in
a degraded state, refer to "HP Systems Insight Display and
LEDs.")
Red = System health is critical. (To identify the component in a
critical state, refer to "HP Systems Insight Display and LEDs.")
Off = System health is normal when in standby mode
Cisco NAC Appliance Hardware Installation Guide
NAC-3310, NAC-3350, and NAC-3390
6 7 8
3
4
5
6
1-25
