Chapter 1 Cisco NAC Appliance Hardware Platforms
NAC-3315, NAC-3355, and NAC-3395
Table 1-1 Cisco NAC Appliance Hardware Summary
Cisco NAC
Appliance Product
MANAGER
NAC-3315
Lite Manager
supporting up to 3
standalone or
HA-pair CASs
SERVER
CAS supporting
100, 250, or 500
users
OL-20326-01
Hardware Specifications
• Single processor: Quad-core Intel Xeon (Core 2
quad)
4GB RAM
•
2 x 250 GB SATA HDD
•
• 4 10/100/1000 LAN ports [2 integrated NICs; 2
Gigabit NICs (PCI-E)]
CD/DVD-ROM Drive
•
• 4 USB Ports (2 front, 2 rear)
• Power supply: 350W
Note The NAC-3315 is based on the
x3250 M2 server platform.
NAC-3315, NAC-3355, and NAC-3395
Diagrams
IBM System
Cisco NAC Appliance Hardware Installation Guide
• Figure 1-2 on
page 1-5 "Cisco
NAC-3315 Front
Panel"
Figure 1-3 on
•
page 1-6 "Cisco
NAC-3315 Front
Panel LEDs/Buttons"
• Figure 1-4 on
page 1-6 "Cisco
NAC-3315 (With
Installed FIPS Card)
Rear Panel"
Figure 1-5 on
•
page 1-7 "Cisco
NAC-3315 (With
Installed FIPS Card)
Rear Panel LEDs"
1-3
