Installing the Clean Access Server
Connect the Clean Access Server
To install the Clean Access Server software from CD-ROM or to perform its initial configuration, you
will need to connect the target machine and access the CAS command line interface.
The Clean Access Server requires two 10/100/1000BASE-TX interface connectors on the back panel of
Step 1
the CAS for its eth0 (trusted) and eth1 (untrusted) network interface. Connect the NIC1 (eth0) network
interface on the target machine to your local area network (LAN) using a CAT5 Ethernet cable.
Do not physically connect the eth1 (NIC2) untrusted network interface on a Virtual Gateway CAS until
Warning
the proper configuration has been performed. Refer to
from CD-ROM, page 3-22
Connect the power by plugging one end of the AC power cord into the back of the machine and the other
Step 2
end into an electrical outlet.
Connect the external FIPS Smart card reader module to a FIPS 140-2 compliant NAC-3315, NAC-3355,
Step 3
or NAC-3395 by plugging the Smart card reader mini-DIN cable into the female mini-DIN FIPS card
port on the back of the appliance (see
on page
Power on the machine by pressing the power button on the front of the appliance. The diagnostic LEDs
Step 4
will flash a few times as part of an LED diagnostic test. Status messages are displayed on the console as
the CAS boots up.
Access the command line or the CAS by either:
Step 5
a.
b.
Cisco NAC Appliances assume the keyboard connected to be of US layout for both direct and IP-KVM
Note
connections. Use a US layout keyboard or ensure that you know the key mapping if you are connecting
a keyboard of different layout.
Static IP addresses must be configured for the CAM/CAS interfaces. DHCP mode is not supported for
Note
configuration of these interfaces.
Install the Clean Access Server (CAS) Software from CD-ROM
The following steps describe how to perform optional CD installation of the Clean Access Server
software on NAC-3310/3315 SERVER or NAC-3350/3355 SERVER appliances.
Cisco NAC Appliance Hardware Installation Guide
3-22
for details.
1-14). (Ensure you also have a Smart card inserted into the reader.)
Connecting a monitor and keyboard directly to the CAS via the keyboard connector and video
monitor/console connector on the back panel.
Or, connecting a serial cable from an external workstation (PC/laptop) to the CAS and open a serial
connection using terminal emulation software (such as HyperTerminal or SecureCRT) on the
external workstation, as described in
Chapter 3
Installing the Clean Access Manager and Clean Access Server
Install the Clean Access Server (CAS) Software
Figure 1-4 on page
1-6,
Figure 1-9 on page
Serial Connection to the CAM and CAS, page
1-10, and
Figure 1-14
3-39.
OL-20326-01
