NAC-3315, NAC-3355, and NAC-3395
NAC-3395 Serial Number Location
The serial number label is located at the lower left of the front-panel of the NAC-3355. (See
Figure
Figure 1-11
Note The serial number for the NAC-3395 is 7 characters long. You can also view the NAC-3315 serial
number location on the Cisco Support website using the Cisco Product Identification Tool. For details,
see
Cisco NAC-3395 Front and Rear Panels
The Cisco NAC-3395 FIPS 140-2 compliant platform provides the enhanced processing, memory, and
power necessary for enterprise wide deployment of the Clean Access Super Manager (Super CAM)
which can support up to 40 Clean Access Servers or 40 HA-CAS pairs. The Cisco NAC-3390 features
dual processors, dual power supplies, 4 GB of RAM, 4 hard disk drives, 4 network interfaces, and an
SSL accelerator card. For additional details, see
Platforms, page
The Super CAM software is supported only on the Cisco NAC-3395 and Cisco NAC-3390 platforms.
Note

Front Panel Features

Figure 1-12
1
2
3
4
Cisco NAC Appliance Hardware Installation Guide
1-12
1-11.)
NAC-3395 Appliance Serial Number Location
XXXXNNNNNNN
Cisco Product Identification Tool, page
1-1.
Cisco NAC-3395 Front Panel
1 2
13 12
Hard disk drive (HDD) bay 0
Hard disk drive (HDD) bay 2
Empty (unused) hard disk drive (HDD) bay
Power button with LED indicator (bicolor:
green/amber)
Chapter 1
1-27.
FIPS 140-2 Compliant and Non-FIPS Hardware
3 4 5
10
11
8
Front USB port 1
9
Front USB port 2
1 10
CD-ROM/DVD drive
11
Empty (unused) hard disk drive (HDD) bay
Cisco NAC Appliance Hardware Platforms
Cisco NAC 3355 Series
NAC Manager
CISCO
6 7 8
Cisco NAC 3395 Series
NAC Manager
CISCO
9
1
