Installing the NAC-3355/3395 Slide Rails Into the 4-Post Rack

When installing the NAC-3355/3395 slide rails in your equipment rack, Cisco recommends using cage
nuts with square-holed racks, clip nuts with round-holed racks, and your own rack screws with
thread-hole racks.
Note If the slide rails that arrived in your shipping container include shipping thumbscrews, remove them
before performing the following procedure.
Identify an available space in your rack to install the NAC-3355/3395.
Step 1
Step 2 If you have either a round-holed or square-holed rack, install cage nuts or clip nuts, in the middle and
bottom holes of the rack unit space on each side of the rack your NAC-3355/3395 will occupy (see
Figure
Install cage nuts or clip nuts in the top and bottom holes for each side of the respective rear rack
Step 3
mounting rails (see
Cisco NAC Appliance Hardware Installation Guide
2-22
shows the items that you need to install the NAC-3355/3395 appliance in a 4-post rack.
NAC-3355/3395 Rack Installation Kit Contents
Cable-management
arm mounting bracket
(Not used)
Cable-management
arm assembly
(2)
Front of rails
10-32 screws
Figure 2-9
2-10).
Figure 2-10).
Slide rail
12-24 screws M6 screws
(13)
(13) (13)
are shipped in the NAC-3355/3395 shipping container, not necessarily
Chapter 2 Preparing for Installation
Slide rail
(left)
(right)
Large
cable tie
(1)
Cable ties
(5)
Cage nuts
(13)
Clip nuts
(13)
