Server - Fortinet FortiGate FortiGate-60M Administration Manual

System DHCP

Server

FortiGate-60M Administration Guide
To configure an interface to be a DHCP server
You can configure a DHCP server for any FortiGate interface. As a DHCP server, the
interface dynamically assigns IP addresses to hosts on the network connected to the
interface. You can also configure a DHCP server for more than one FortiGate
interface.
1 Go to System > DHCP > Service.
2 Select Edit beside the interface to which you want to add a DHCP server.
3 Select DHCP Server.
4 Select OK.
5 Add a DHCP server configuration for this interface.
See "To configure a DHCP server for an interface" on page
You can configure one or more DHCP servers for any FortiGate interface. As a DHCP
server, the interface dynamically assigns IP addresses to hosts on a network
connected to the interface.
You can add more than one DHCP server to a single interface to be able to provide
DHCP services to multiple networks. For more information, see
DHCP servers for an interface" on page
Figure 23: DHCP Server list
Create New
Name
Interface
Default Gateway
Delete
Edit/View icon
Add a new DHCP server.
Name of the DHCP server.
The interface for which the DHCP server is configured.
The DHCP server configuration default gateway
Delete a DHCP server configuration.
View or modify a DHCP server configuration.
01-28007-0144-20041217
78.
79.
Server
"To configure multiple
77
