Router
FortiGate-60M Administration Guide
config router ospf
config area
show
end
config virtual-link
Access the config virtual-link subcommand using the config area
command.
Use virtual links to connect an area to the backbone when the area has no direct
connection to the backbone. A virtual link allows traffic from the area to transit a
directly connected area to reach the backbone. The transit area cannot be a stub
area. Virtual links can only be set up between two area border routers (ABRs).
config virtual link command syntax pattern
config virtual-link
edit <name_str>
set <keyword> <variable>
end
config virtual-link
edit <name_str>
unset <keyword>
end
config virtual-link
delete <name_str>
end
config virtual-link
edit <name_str>
get
end
config virtual-link
edit <name_str>
show
end
Note: Only the peer keyword is required. All other keywords are optional.
01-28007-0144-20041217
edit 15.1.1.1
