Users and authentication

RADIUS

RADIUS server list

FortiGate-60M Administration Guide
LDAP
Radius
To add a user name and configure authentication
1 Go to User > Local.
2 Select Create New to add a new user name or select the Edit icon to edit an existing
configuration.
3 Type the User Name.
4 Select the authentication type for this user.
5 Select OK.
To delete a user name from the internal database
You cannot delete user names that have been added to user groups. Remove user
names from user groups before deleting them.
1 Go to User > Local.
2 Select the Delete icon for the user name that you want to delete.
3 Select OK.
Note: Deleting the user name deletes the authentication configured for the user.
If you have configured RADIUS support and a user is required to authenticate using a
RADIUS server, the FortiGate unit contacts the RADIUS server for authentication. The
default port for RADIUS traffic is 1812. If your RADIUS server is using port 1645 you
can use the CLI to change the default RADIUS port. For more information see the
config system global command entry in the FortiGate CLI Reference Guide.
Figure 115:RADIUS server list
Create New
Name
Select LDAP to require the user to authenticate to an LDAP server. Select
the name of the LDAP server to which the user must authenticate. You can
only select an LDAP server that has been added to the FortiGate LDAP
configuration. See "LDAP" on page
Select Radius to require the user to authenticate to a RADIUS server. Select
the name of the RADIUS server to which the user must authenticate. You
can only select a RADIUS server that has been added to the FortiGate
RADIUS configuration. See
Add a new RADIUS server.
The RADIUS server name.
01-28007-0144-20041217
238.
"RADIUS" on page 237.
RADIUS
237
