Virtual IP

Configuring recurring schedules

Virtual IP
216
To add a recurring schedule
1 Go to Firewall > Schedule > Recurring.
2 Select Create New.
3 Enter a name for the schedule.
4 Select the days of the week that you want the schedule to be active.
5 Set the Start and Stop time for the recurring schedule.
Recurring schedules use a 24-hour clock.
6 Select OK.
To delete a recurring schedule
1 Go to Firewall > Schedule > Recurring.
2 Select the Delete icon beside the recurring schedule you want to delete.
3 Select OK.
To edit a recurring schedule
1 Go to Firewall > Schedule > Recurring.
2 Select the Edit icon beside the recurring schedule you want to modify.
3 Modify the schedule as required.
Note: To change the one-time schedule name you must delete the schedule and add it with a
new name.
4 Select OK.
Use virtual IPs to access IP addresses on a destination network that are hidden from
the source network by NAT security policies. To allow connections between these
networks, you must create a mapping between an address on the source network and
the real address on the destination network. This mapping is called a virtual IP.
For example, if the computer hosting your web server is located on your DMZ
network, it could have a private IP address such as 10.10.10.3. To get packets from
the Internet to the web server, you must have an external address for the web server
on the Internet. You must then add a virtual IP to the firewall that maps the external IP
address of the web server to the actual address of the web server on the DMZ
network. To allow connections from the Internet to the web server, you must then add
a WAN1->DMZ or WAN2->DMZ firewall policy and set Destination to the virtual IP.
