SNMP
106
Table 14: System MIB fields
MIB field Description
model FortiGate model number, for example, 400 for the FortiGate-400.
serial FortiGate unit serial number.
version The firmware version currently running on the FortiGate unit.
versionAv The antivirus definition version installed on the FortiGate unit.
versionNids The attack definition version installed on the FortiGate unit.
haMode The current FortiGate High-Availability (HA) mode (standalone, A-A, A-P)
opMode The FortiGate unit operation mode (NAT or Transparent).
cpuUsage The current CPU usage (as a percent).
memUsage The current memory utilization (in MB).
sesCount The current IP session count.
Table 15: HA MIB fields
MIB field Description
groupId HA group ID.
priority The clustering priority of the individual FortiGate unit in a cluster.
override The master-override setting (enable or disable) for an individual FortiGate unit in
a cluster.
autoSync Auto config synchronization flag.
schedule Load balancing schedule for A-A mode.
stats Statistics for all of the units in the HA cluster.
index
serial
cpuUsage
memUsage The current FortiGate unit memory usage (in MB).
netUsage
sesCount
pktCount
byteCount
idsCount
avCount
01-28007-0144-20041217
The index number of the FortiGate unit.
The FortiGate unit serial number.
The current FortiGate unit CPU usage as a percent.
The current FortiGate unit network utilization (in Mbps).
The number of active sessions being processed by the FortiGate
unit.
The number of packets processed by the FortiGate unit.
The number of bytes processed by the FortiGate unit
The number of attacks detected by the IPS running on the
FortiGate unit in the last 20 hours.
The number of viruses detected by the antivirus system running
on the FortiGate unit in the last 20 hours.
