Upgrading The Firmware Using The Cli - Fortinet FortiGate FortiGate-60M Administration Manual

Changing the FortiGate firmware
34
3 Go to System > Status.
4 Under Unit Information > Firmware Version, select Update.
5 Type the path and filename of the firmware image file, or select Browse and locate the
file.
6 Select OK.
The FortiGate unit uploads the firmware image file, upgrades to the new firmware
version, restarts, and displays the FortiGate login. This process takes a few minutes.
7 Log into the web-based manager.
8 Go to System > Status and check the Firmware Version to confirm that the firmware
upgrade is successfully installed.
9 Update antivirus and attack definitions. For information about updating antivirus and
attack definitions, see

Upgrading the firmware using the CLI

To use the following procedure you must have a TFTP server that the FortiGate unit
can connect to.
Note: Installing firmware replaces your current antivirus and attack definitions with the
definitions included with the firmware release that you are installing. After you install new
firmware, use the procedure
sure that antivirus and attack definitions are up to date. You can also use the CLI command
execute update_now
1 Make sure that the TFTP server is running.
2 Copy the new firmware image file to the root directory of the TFTP server.
3 Log into the CLI.
Note: To use this procedure you must login using the admin administrator account, or an
administrator account that has system configuration read and write privileges.
4 Make sure the FortiGate unit can connect to the TFTP server.
You can use the following command to ping the computer running the TFTP server.
For example, if the IP address of the TFTP server is 192.168.1.168:
execute ping 192.168.1.168
"Update center" on page
"To update antivirus and attack definitions" on page 123
to update the antivirus and attack definitions.
01-28007-0144-20041217
120.
System status
to make
Fortinet Inc.
