Configuring the Keyboard/User
Priority Settings
The Keyboard/User Priorities setup allows you to
create up to eight priority levels that can be assigned
to keyboards and users. Each priority level grants a
different level of permission for control of cameras or
the system.
To configure the Keyboard/User priority settings, do
the following within the Priority Settings tab:
1. Click on Keyboard/User Priorities link in the
Explore menu to begin. The following screen
appears.
Figure 93. Definitions – keyboard/user priorities
settings screen
2. In the Priorities Settings tab, complete the
following fields:
− Priority No. – Identifies a level (1-8) to this
priority (1 = lowest priority, 8 = highest priority).
− Reset System – If enabled, the selected
priority level can clear all programmed
information from the CPU and return to factory
defaults.
− Lock Camera – If enabled, the selected priority
level can lock the control of a camera (equal or
lower priority levels will have view-only
capability).
− Override – If enabled, the selected priority
level can override the keyboard/camera view
and control partitioning restrictions.
− Menu Access – If enabled, the selected priority
level can access menu programming.
− Change Parameters – If enabled, the selected
priority level can edit system parameters
through menu programming (must have menu
access).
− Add User – If enabled, the selected priority
level can add new users.
MEGAPOWER CPU
ADMINISTRATOR'S GUIDE
Deleting Keyboard/User Priorities Settings
To delete a keyboard, user, or priority settings:
1. Click on the appropriate tab.
2. Left mouse click on the leftmost blue portion of
the row containing the desired definition. The
entire row turns blue.
3. Press Delete on the PC keyboard. The Delete
Row dialog box appears.
Figure 94. Delete Row dialog
4. Click Yes to delete the definition or No to retain
the definition.

Defining Satellite Sites

The Satellite Sites setup allows you to identify
satellite sites and their port connections on the
MegaPower CPU.
1. Click on the Definitions – Satellite Sites link to
begin. The following screen appears.
Figure 95. Satellite sites screen
2. To define satellite sites, complete the following
fields:
− Site – Enter the unique site number (1-30) of
the satellite system. The unique site number
was created at the satellite site during setup.
− Host Port – Enter the port to which the satellite
is connected on the local MegaPower CPU.
The same port must be selected on the System
– Port Configuration screen.
− Remote Port – Enter the communication port
on the satellite system.
