- Page 1 ® VideoEdge NVMS (Network Video Management System) Design Guide Version 1.0 Part Number 8200-2637-01 A0...
-
Page 2: Customer Service
Customer Service Thank you for using American Dynamics products. We support our products through an extensive worldwide network of dealers. The dealer through whom you originally purchased this product is your point of contact if you need service or support. Our dealers are empowered to provide the very best in customer service and support. -
Page 3: Table Of Contents
Hardware Products:........................... 6 Network Infrastructure....................7 Network Equipment ........................... 7 Network Protocols ............................. 7 Understanding the VideoEdge NVMS Network Topology.......... 8 Distributed versus Centralized Architectures .................... 8 VideoEdge NVMS Network Channels ....................... 9 Understanding Network Traffic for IP Video ............. 11 Impact of Video Codec .......................... -
Page 4: Overview
The purpose of this document is to provide customers, security and network integrators, consultants, administrators, engineers, and IT professionals alike with an understanding of how the VideoEdge Network Video Management System functions as an enterprise IP-based video surveillance solution and how to deploy the various solution components into a new or existing Ethernet network. - Page 5 VideoEdge NVMS Design Guide Example of VideoEdge Multi-Site Installation with Virtual Matrix Video Wall...
-
Page 6: Videoedge Nvms Summary
VideoEdge also supports a video wall that can enable one or more clients to manage any large number of standard Windows client PC’s with single or dual monitor configurations running our virtual matrix video wall software that can span across the network. -
Page 7: Hardware Products
Online software registration will be required to receive appropriate software license. • ADN024S0300 • ADN032S0375 American Dynamics VideoEdge NVR can scale in storage by adding the Fibre RAID Storage. This kit will Fibre HBA Kit Adapter include the Fibre Card, Fibre Cables and Transceivers necessary to connect the NVR to •... -
Page 8: Network Infrastructure
Network Equipment American Dynamics does not endorse one brand over another as VideoEdge is designed to work with standard Ethernet equipment. Although there is a wide range of models to choose from, it is important to choose the correct hardware to ensure sustained network bandwidth, reliability for maximum uptime, and advanced port management functions which are critical for any IP video deployment. -
Page 9: Understanding The Videoedge Nvms Network Topology
Understanding the VideoEdge NVMS Network Topology The VideoEdge NVMS is designed as a scalable solution to support the needs of various resolution, compressions, and real-time video monitoring in a distributed and centralized architectures. Careful planning and deployment will be required to ensure that the highest level of performance can be achieved based on the network infrastructure. -
Page 10: Videoedge Nvms Network Channels
It is recommended that high quality layer 3 switches are used whenever possible to ensure a more efficiently designed infrastructure where priorities for video traffic can be configured as needed along with VLAN configurations. Example of VideoEdge NVR Server Utilizing 3 GbE NICs (Client & Camera & IP SAN Storage) - Page 11 VideoEdge NVMS Design Guide Example of VideoEdge NVR Server Utilizing 2 GbE NICs (Client & Camera) and Fibre Direct Attached Storage NOTE: The network implementations in this document are shown as general representations only and are not intended to show detailed network topologies. Each VideoEdge NVMS installation site will have different configuration and equipment requirements.
-
Page 12: Understanding Network Traffic For Ip Video
For Intra/Reference Frame compression algorithms, when there is higher video activity, the resulting data rate will greatly increase and in some cases be larger than MJPEG. The VideoEdge NVR currently supports the following codec: Bandwidth... -
Page 13: Impact Of Compression
VideoEdge NVMS supports single streams for each device and unicast. This impact must be split into two parts: • Video Input: Number of streams that can be received by the VideoEdge NVR (e.g. LAN2 traffic from IP cameras and encoders) VideoEdge NVR can support as little as one video channel or as many as 128 video channels. -
Page 14: Calculating Bandwidth And Storage Requirements For Recording
As explained in earlier sections, there are many possible setting combinations that can be applied to each individual video device. As VideoEdge NVMS is designed as an open platform, it supports video devices from American Dynamics as well as from various third party vendors. As each make/model device has different characteristics, we will utilize the third party vendor’s calculators to determine the individual data... -
Page 15: Calculate Individual Data Rates
Calculate Total Bandwidth and Storage Requirements Once the individual data rates are captured, go to the VideoEdge NVR Storage Requirement Calculator determine the total storage and bandwidth requirements. 6. Enter the Model, Calculated Data Rate and select the units (#4 above) 7. - Page 16 NVR. Save the screenshot for future reference. Additional calculation figures may need to be processed if you wish to determine the optimal storage and bandwidth usage for each NVRs Example of Calculated Total Storage and Bandwidth Requirements for a Single VideoEdge NVR with 64 Cameras...
-
Page 17: How To Calculate Bandwidth Requirements For Viewing
Cx Alert Console: This client application will capture alerts from multiple VideoEdge NVRs and provides ability to view live and recorded alert video. It can support a round-robin spot monitor or standard 4 and 9 camera view layout.
