APPENDIX E: Auxiliary Key Code Functions

The following special function keys enable you, using the keyboard, to manually operate and control cameras.

F1 Special Function Keys

Function Action
Releases keyboard control of video
F1
trunk
1-F1 Unlocks the current camera
2-F1 Locks the current camera
Take snapshot of currently selected
monitor and store on a remote IP
4-F1
1
server
19-F1 Flip Camera 180°
21-F1 Run Pattern 1
22-F1 Run Pattern 2
23-F1 Run Pattern 3
Ping SensorNet Dome
29-F1
30-F1 Reset Dome
31-F1 Go to start of Pattern 1

F2 Special Function Keys

Function Action
Sets on-screen Time and Date
1-F2
display ON
Sets on-screen Time and Date
2-F2
display OFF
Sets Camera Title, Number, &
3-F2
Status display ON
Sets Camera Title, Number, &
4-F2
Status display OFF
Displays titles & date/time at the top
5-F2
of the screen
Displays titles & date/time at the
6-F2
bottom of the screen
Sets on-screen Time, Date, & Title
7-F2
display ON
Sets on screen Time, Date, & Title
8-F2
display OFF
Sets date format to month-day-year
21-F2
(MM-DD-YY)
Sets date format to day-month-year
22-F2
(DD-MM-YY)
MEGAPOWER CPU
ADMINISTRATOR'S GUIDE
(1)(2)
(1)(2)
60 of 72
Function Action
32-F1 Go to start of Pattern 2
33-F1 Go to start of Pattern 3
41-F1 Auto Repeat Pattern 1
42-F1 Auto Repeat Pattern 2
43-F1 Auto Repeat Pattern 3
44-F1 Run Apple Peel Pattern
Return to Auto Iris/Auto Focus
69-F1
70-F1 Set Aux 4 Off
71-F1 Set Aux 4 On
99-F1 Logoff from passcode Logon
Notes:
(1)
Not supported with the AD1024 CPU
(2)
For SensorNet domes only
Function Action
Sets date format to year-month-day
23-F2
(YY-MM-DD)
24-F2 Steps through date formats
Enter/Exit Line Lock phase
38-F2
adjustment mode
Enter/Exit Line Lock phase
39-F2
adjustment mode (same as 38-F2)
Sets date format to month-day-year
41-F2
(MM-DD-YY)
Sets date format to day-month-year
42-F2
(DD-MM-YY)
Sets date format to year-month-day
43-F2
(YY-MM-DD)
44-F2 Steps through date formats
Disables bell at keyboard for all RS–
45-F2
232 ports
Enables bell at keyboard for all
46-F2
RS-232 ports
(1)(2)
(1)(2)
(1)(2)
