• Disabled – Alarm table set in column 2 is
disabled for the day set in column 1
• Enabled – Alarm table set in column 2 is
enabled for the day set in column 1
• Not Used – Alarm table set in column 2 is
not used for the day set in column 1
Event Timer – Tours
Event Timers enable the automatic call up of Tours
and alarm monitor/contact tables on specific days at
specific times. By scheduling these activities to occur
automatically, you can help ensure the surveillance
of key areas at important times. The MegaPower
CPU allows you to create 35 Event Timers.
Click on the Tours tab in the Switching – Event Timer
link in the Explore menu to begin. The following
screen appears.
Figure 63. Event timer–Tours tab screen
Scheduling System Tours with the Event
Timer
To schedule system Tours using the event timer
feature, you will need the following information:
• The number of the system Tour you want to run
• The number of the monitor you want to display
the system Tour
• The day(s) of the week you want to Tour to run
• The hour of the day or night you want the Tour to
run
To create a system Tour using the Event Timer, click
on the Tours tab and complete the following fields:
• MonitorNumber – Number of the monitor where
the tour is to be displayed
• Sunday through Saturday – Day of the week on
which the tour is to run
Deleting Tours in the Event Timer Screen
To delete a Tour in the event timer screen:
1. Left click the left header of the row in the left
screen that contains the time of the Tour to be
deleted.
MEGAPOWER CPU
ADMINISTRATOR'S GUIDE
2. Left click the left header of the row in the right
screen that contains the Tour to be deleted.
3. Press the keyboard Delete key of the PC running
EASY CPU. The Delete Rows dialog box
appears.
Figure 64. Delete Rows dialog
4. Click Yes to delete the Tour or No to close the
dialog box without deleting the Tour.

Configuring Alarms

The MegaPower CPU can respond to 4,096 alarms
by calling cameras, salvos, or Presets to armed
monitors and turning auxiliary devices on or off.
These alarm responses are defined in tables called
Alarm Monitor/Contact Tables.
EASY CPU provides one master Alarm
Monitor/Contact Table and four additional tables for
customizing monitor assignments. The master Alarm
Monitor/Contact Table conforms to the site
configuration of alarms and their associated cameras
and auxiliary devices. You should alter this table only
if the site configuration changes or in the event of
errors in previous data entries.
Each of the additional tables contains the same
associations of alarms to cameras, salvos, presets
and auxiliary devices as the master Alarm
Monitor/Contact Table. The difference between the
master table and any of the additional tables is in the
association of monitors to each alarm. You can
change the monitor associations in any of the
additional tables.
The system routes alarms to monitors depending on
which Alarm Monitor/Contact Table is active at the
time of the alarm. You can schedule Alarm
Monitor/Contact Tables to become active
automatically through Event Timers (see page 27).
Click on the Alarms links in the Explore menu to
begin (Figure 65 on page 29).
