Logging In Users For Cpu Read/Write Access - American Dynamics MegaPower 3200 Administrator's Manual

Figure 44. Login Properties dialog
4. Complete the Login ID, Password, and Confirm
fields in the Login Properties dialog box for the
new user.
5. In the Access Level field, click on the scroll
buttons to choose the appropriate access level for
the new user (1 being the lowest level, 9 being the
highest level).
Note: The Access Level field is grayed out for the
first user so that user will have all administrator
privileges. This field is available to set access
levels for subsequent users.
CAUTION: Be sure that at least one user has an
access level of 9. Failure to maintain such a user
might lock users out of the system and require a
system reinstallation.
6. Click OK to save the new user properties or
Cancel to close the dialog box without saving the
properties.
7. Repeat this process for all users for whom logins
are desired.
Note: You also can modify or delete users in the
Login Properties dialog box whenever buttons are
not grayed out.
8. Be sure to save these changes and write the
modified configuration file to the CPU.
Note: With the user login function enabled, all newly
initiated program sessions will require users to log in
before reading or writing configuration data.
MEGAPOWER CPU
ADMINISTRATOR'S GUIDE
Logging in Users for CPU
Read/Write Access
When user logins are enabled, the Login dialog box
appears whenever you want to read a configuration
file from the CPU or write a configuration file to the
CPU.
Figure 45. Login dialog
1. In the Login dialog box, enter your user name and
password.
2. Click Logon to transfer configuration data or
Cancel to close the dialog box without transferring
configuration data.
18 of 72
8200-0421-03, REV. D
