Figure 72. Alarms – contact definitions screen
To create Alarm Monitor/Contact Tables, complete
the following fields:
• Contact No. – Determined by the following:
− MPCPU port designation Alarms (1-1024),
Alarms (1025-2048), Alarms (2049-3072), or
Alarms (3073-4096), and either:
• The physical contact point on the AD2096A
Alarm Interface Unit and the AD2096A DIP
switch settings, or
• The dome address and the AD2083-xx
RS-422 Distributor's DIP switch setting for
the Number of Alarm Contacts per Dome
• Camera or Salvo – Specifies the camera pseudo
number or Salvo to be called when the alarm
activates. If the Link field is set to Salvo or Salvo
Group Ack, the number in this field refers to the
Salvo number.
• Preset Pattern – Indicates the Preset number
(0-72) assigned to the camera number selected
above.
• Link – Allows linking of a contact definition to
another contact definition, salvo, or wired set of
alarm contacts. Linked options are:
– No - Indicates that the alarm contact entry
either is not linked with another alarm contact
or is the last entry of a linked group of alarm
contacts.
– Yes - Indicates that the alarm contact entry will
be linked to the next alarm contact entry
programmed into the system. A group of
contacts linked in this way emulates a system
Salvo (more than one camera action runs in
response to an alarm).
– Salvo - Indicates that the alarm contact entry
will call a Salvo to a block of monitors.
− Wired - Indicates that the alarm contact entry
will be linked to the following entry in a wired
set. A wired set is a set of alarm contacts.
When any member of the set is activated, all
members of the set are activated.
MEGAPOWER CPU
ADMINISTRATOR'S GUIDE
Each member of a wired set must be
designated as "Wired Set" or "Wired Group
Ack," except the last member of the set, which
must be designed as "No," "No Group Ack,"
"Salvo," or "Salvo Group Ack."
− No Group Ack, Yes Group Ack, Salvo Group
Ack, Wired Group Ack – When an alarm is
cleared manually by a keyboard operator, all
alarms in the wired set are cleared.
• Aux – Identifies an auxiliary device to be included
as an action when this alarm activates. Choose
from the following:
– Don't Care – Ignores the auxiliary
– Aux 1-4 On – Activates auxiliaries 1, 2, 3, or 4
when an alarm is triggered
– Aux 1-4 Off – Deactivates auxiliaries 1, 2, 3, or
4 when an alarm is triggered
• Dwell – When the monitor is armed to sequence
alarms, the dwell time specifies how long an
alarm stays on screen before the next alarm in
queue takes its place. Options are 1-60 seconds.
• Alarm Message – Message that appears on a
given monitor when an alarm is activated. Alarm
messages are created in the Alarm – Alarm
Messages screen.
After the alarm message is created, enter the
alarm message number in the Alarm Messages
field of the Alarm – Contact Definitions screen.
• Email Message – Text of Email message
delivered to recipients configured in Alarms –
Email messages screen. An Email message can
be sent to any Email address in the world in the
event of an alarm.
To create a message, click on the field and the
following choice appears:
− <<Add New...>> – When you select this, click
again outside this field and the following dialog
box appears (Figure 73 on page 33).
