Table 101-1. Soneplex Broadband System (V5) Specifications, continued
PARAMETER
Version D and later HLXRs; HLXR 3192
DS1 Interface:
Input / Output Signals
Frequency
HDSL Interface:
Format
Impedance
Loop Loss
Loop Type
Output Signal Level
Return Loss
Power
Version A and Version B HRXs
Impedance
Input Voltage
Loop Loss Allowed
Output Signal Level
Power Consumption
ODS2 Module
Fiber Cable
Line Rate
Number of Fibers
Operating Wavelength
Optical Budget
Optical Connector
Optical Transmit Power
Receive Device
Receiver Dynamic Range
Transmit Device
2-252
© 2000, ADC Telecommunications, Inc.
SPECIFICATION
Per ANSI T1-403
1.544 Mbps
Two 784 kbps full duplex pairs
135 ohms
<35 dB
Two pair, single or mixed gauges With or without bridged taps
+13.5 dBm
>20 dB
–42.5 to –56.5 VDC (local)
130 VDC or ±130 VDC (line)
–
135 ohms
Up to ±130 VDC nominal
Up to 35 dB
13.5 ±0.5 dBm
6.2 watts (max. per repeater)
9/125 µm single mode
6.312 Mbps ± 20 ppm
Two single mode
1300 nm ± 40 nm
22.0 dB (minimum)
FC or SC type (Tx/Rx)
–7 dBm ± 2 dB
PIN Photodiode
-9
–5 to –31 dBm @10 BER
Laser
REMARKS
HLXR 3192 only: ±200 bps
received signal tolerance;
±50 bps generated signals
2B1Q
196 kHz
40 to 200 kHz
Version D HLXR only
Constant voltage differential
between loops 1 and 2 can vary
from 42 VDC to 260 VDC
HLXC to HRX, first HRX to
second HRX, and HRX to HLXR
All power dissipated in the unit.
Nominal
Per ODS2 module
Average power
