ADCP-61-471 • Issue 4 • June 2000 • Section 2: Operation and Maintenance
DLP-570
Page 4 of 18
7. To start a test, set the Measurement field to START. The RTAU waits for pattern sync or
frame sync (for framed patterns) before beginning measurement (see
syncing, the test begins and the Measurement display changes to RUNNING.
8. As a test progresses, the results are displayed on the RTAU Config screen, in the 'Error
Counts' and 'Elapsed Time' columns.
9. To terminate a test, set the Measurement field to STOP. Setting the Mode field to
DISABLE also stops any measurements in progress and terminates the test.
10. To end a test session and restore the tested circuit to normal operation, set the Mode field to
DISABLE.
Stop! You have completed this procedure.
EQUIPMENT SETUP
===============
Current User
Line Code
SIGNAL GENERATOR SETUP
======================
Pattern Type
Frame Format
Loop Code
BIT ERROR SETUP
===============
Error Count
Error Rate
Error Locn
Test Timeout
In Minutes
(Showing Defaults for Screen With Line Code Field Set to INTERNAL)
2-214
© 2000, ADC Telecommunications, Inc.
RTAU CONFIG
: CRAFT
: INTERNAL
: QRS -------------------------------------
: UNFRAMED
: NONE
Error Counts
============
: 0 Data :
: OFF BPV :
: N/A Frame:
CRC :
COFA :
: 60 Measurement : STOP
Press CONTROL-A For Assistance
Figure 570-4. RTAU Config Screen
Figure 570-15). After
Test Circuit: 1-1
Mode : DISABLE
---------------
Status Elapsed Time
====== ============
F Sync: ES :
P Sync: EFS:
RAI :
14866-A
