Summary: Use this command to display the status of the working and protect Soneplex ODS2
modules installed in the selected chassis.
Note: Press CONTROL-A for help information about moving around and editing fields.
1. Use the arrow keys to select Display Status from the Main Menu. Press Enter or Return.
2. Use the arrow keys to select Display ODS2 Status from the Display Status menu. Press
Enter or Return. A Display ODS2 Status screen is shown in
3. Move to the Group toggle field. Select group number 1, 2, 3, 4, 5, 6, or 7.
Reference: TAD-106
Stop! You have completed this procedure.
Unit Online Status: ONLINE
HSKP1/HSKP2
Optical Status
Optical Comm Fail :
Laser Degrade
Mate Comm Fail
Config Mismatch
Version Mismatch
Board Fail
Optical BER Alarm :
APS Status
APS Lockout
DS1 Number
DS1 Online Status : Y Y Y Y
DS1 Lpbk Active
Receive DS1 LOS
Receive DS1 AIS
ADCP-61-471 • Issue 4 • June 2000 • Section 2: Operation and Maintenance
ODS2 MODULE STATUS DISPLAY
Access Identifier
ODS2 STATUS
Group: 3
LOCAL
Working Protect
------- -------
: N/A N/A
: LOS
NO
: NO
: N/A
: NO
: NO
: NO
NO
: ENABLED
: NO
: 1 2 3 4 1 2 3 4
======= =======
: N N N N
: - - - -
: - - - -
Figure 547-1. ODS2 Status Screen
DLP-547
Page 1 of 1
Figure 547-1.
REMOTE
Working Protect
------- -------
1 2 3 4 1 2 3 4
======= =======
6140-B
