ADC Soneplex Broadband System Operation And Maintenance Manual page 180

Summary: This procedure provides instructions for displaying the status of the working and
protect Soneplex DS3 MUX modules installed in the chassis.
Note: Press CONTROL-A for help information about moving around and editing fields.
1. Use the arrow keys to select Display Status from the Main Menu. Press Enter or Return.
2. Use the arrow keys or number keys to select Display MUX Status from the Display Status
menu (Figure 546-1). Press Enter or Return. A detailed Display Status screen is shown in
Figure 546-2.
Note: DS3 RX Status displays are OK, LOS, OOF, Yellow, AIS, Idle, M13, or C-Bit.
Stop! You have completed this procedure.
ADCP-61-471 • Issue 4 • June 2000 • Section 2: Operation and Maintenance
DS3 MUX STATUS DISPLAY
DISPLAY STATUS
1. Display Shelf Status
2. Display MUX Status
3. Display ODS2 Status
4. Display QLX Status
5. Display HLX Status
6. Display DLX Status
7. Display RLX Status
Press CONTROL-A For Assistance
Figure 546-1. Display Status Menu
DLP-546
Page 1 of 2
9447-A
© 2000, ADC Telecommunications, Inc.
2-157
