Summary: This procedure provides instructions for filtering the alarm notification pop-up,
based on the criticality of the alarm or event. When this feature is used, a beep is also heard each
time the notification pop-up appears. Even with this feature disabled, all alarms and events are
logged in the alarm database. The notification pop-up appears and the beep occurs any time an
alarm occurs that is as critical or more critical than the level at which it is set.
Note: A "toggle" field type means the user can press the space bar to view and select the
next option that is described; or the user can press the "R" key to view and select the
previous option. An "input" field type means the user must type an entry in the field
according to the parameters described. A "fixed" field is locked, and cannot be changed by
the user.
Note: Edits can be made in the configuration database in one of two ways: 1) If the
complete field is highlighted, use the space bar to toggle forward or the "R" key to
reverse toggle through the options for that field. 2) If only the first space or the field is
highlighted, type in the data that applies to that field.
Note: Edits to the configuration database can be saved after each change in one of two
ways: 1) Press an arrow key and then Enter or Return once; or 2) Press Enter or Return
twice after all selections and entries are made in the screen but before leaving the screen.
If the entries have been accepted, a message "Configuration Successful... Press Any Key
To Continue" appears on the screen.
Note: Press CONTROL-A for help information on moving around and editing fields.
1. Use the arrow keys to select Alarms from the Main Menu. Press Enter or Return.
2. Use the arrow keys to select Alarm/Event Notification Level from the Alarms menu. Press
Enter or Return. An Alarm/Event Notification Level screen is shown in
3. Use the space bar to scroll through the options, and stop at the selection you wish to enter.
• Select EVENT to allow notification of all alarms and events as they occur.
• Select MINOR to allow notification of all Minor, Major, and Critical alarms as they
occur.
• Select MAJOR (the default) to allow notification of all Major and Critical alarms as
they occur.
• Select CRITICAL to allow notification of all Critical alarms as they occur.
• Select DISABLED to disable the notification of all alarms and events as they occur.
4. Assign the selection by pressing Enter or Return.
Stop! You have completed this procedure.
ADCP-61-471 • Issue 4 • June 2000 • Section 2: Operation and Maintenance
ALARM/EVENT NOTIFICATION LEVEL SETTING
DLP-552
Page 1 of 2
Figure 552-1.
