1. HLX Unit Configuration
2. Loopback Configuration
Press CONTROL-A For Assistance
Figure 573-1. HLX Configuration Menu
Group: 6
HLXC Activation Code
HLXC Programmable Lpbk
HLXR NID Loopback
HLXR Activation Code
HLXR Programmable Lpbk
HRX Activation Code
HRX Programmable Lpbk
Common Deactivate Code
Lpbk Timeout Disable Code:
Lpbk Timeout Period
Note: "Activation Code" is equivalent to "Programmable Code."
Figure 573-2. HLX Loopback Configuration Screen (MPU V5.1 Without an HRX)
ADCP-61-471 • Issue 4 • June 2000 • Section 2: Operation and Maintenance
HLX CONFIGURATION
HLX LOOPBACK CONFIGURATION
Slot: 1 Circuit ID:
: 1101001111010011
: DISABLED
: UNIT SWITCH
: 1100011101000010
: DISABLED
: NOT APPL
: NOT APPL
: 1001001110010011
1101010111010110
: 30 minutes
Press CONTROL-A For Assistance
DLP-573
Page 2 of 6
6765-A
6697-B
