Circuit Id Display - ADC Soneplex Broadband System Operation And Maintenance Manual

Summary: This procedure provides instructions for displaying the Access ID (AID), Circuit ID,
and the Unit Type for each module installed in the Soneplex Broadband chassis.
Note: Press CONTROL-A for help information about moving around and editing fields.
1. Use the arrow keys to select System Maintenance from the Main Menu. Press Enter or
Return.
2. Use the arrow keys to select Display Circuit IDs from the System Maintenance menu. Press
Enter or Return. A Display Circuit ID menu is shown in
Reference: TAD-106
Stop! You have completed this procedure.
TID : ADC
AID Circuit ID
======= ==================== =========
1-1-1-1
1-1-2-1
1-1-3-1
1-1-4-1
1-2-1-1
1-2-2-1
1-2-3-1
1-2-4-1
1-3-1-1
1-3-2-1
1-3-3-1
1-3-4-1
1-4-1-1
1-4-2-1
ADCP-61-471 • Issue 4 • June 2000 • Section 2: Operation and Maintenance

CIRCUIT ID DISPLAY

Access Identifier
DISPLAY CIRCUIT ID MENU
Unit Type AID
======= ==================== =========
RLX 1-4-3-1
NONE 1-4-4-1
NONE 1-5-1-1
NONE 1-5-2-1
NONE 1-5-3-1
NONE 1-5-4-1
NONE 1-6-1-1
NONE 1-6-2-1
ODS2 1-6-3-1
ODS2 1-6-4-1
ODS2 1-7-1-1
ODS2 1-7-2-1
NONE 1-7-3-1
NONE 1-7-4-1
Press CONTROL-A For Assistance
Figure 566-1. Display Circuit ID Screen
Figure 566-1.
Circuit ID Unit Type
NONE
NONE
DLX
NONE
NONE
NONE
HLX
NONE
NONE
NONE
HLX
NONE
NONE
NONE
© 2000, ADC Telecommunications, Inc.
DLP-566
Page 1 of 1
6155-B
2-205
