HP 3100 v2 Series Command Reference Manual page 98

BPDU Received
TCN: 0, Config: 0, RST: 0, MST: 0
-------[VLAN 2 Global Info]-------
Protocol Status
Bridge ID
Bridge Times
Root ID / RPC
Root PortId
BPDU-Protection
TC or TCN received
Time since last TC
# Display the spanning tree status and statistics when the spanning tree feature is disabled.
<Sysname> display stp
Protocol Status
Protocol Std.
Version
Bridge-Prio.
MAC address
Max age(s)
Forward delay(s)
Hello time(s)
Max hops
Table 23 Command output
Field
CIST Bridge
Bridge ID
Bridge Times
CIST Root/ERPC
CIST RegRoot/IRPC
Root ID / RPC
CIST RootPortId
Root PortId
:0
:enabled
:32768.000f-e200-2200
:Hello 2s MaxAge 20s FwDly 15s
:0.00e0-fc0e-6554 / 200200
:128.48
:disabled
:2
:0 days 0h:5m:42s
:disabled
:IEEE 802.1s
:3
:32768
:000f-e200-8048
:20
:15
:2
:20
Description
CIST bridge ID, which comprises the device's priority in the CIST and its MAC
address. For example, in output "32768.000f-e200-2200", the value preceding
the dot is the device's priority in the CIST, and the value following the dot is the
device's MAC address.
Bridge ID, which comprises the device's priority in VLAN 1 and its MAC
address. For example, in output "32768.000f-e200-2200", the value preceding
the dot is the device's priority in VLAN 1, and the value following the dot is the
device's MAC address.
Major parameters for the bridge:
•
Hello—Hello timer.
•
MaxAge—Max age timer.
•
FWDly—Forward delay timer.
•
MaxHop—Max hops within the MST region.
CIST root ID and external path cost (the path cost from the device to the CIST
root).
CIST regional root ID and internal path cost (the path cost from the device to the
CIST regional root).
VLAN root ID and root path cost (the path cost from the device to the root).
CIST root port ID. "0.0" indicates that the device is the root and there is no root
port.
VLAN root port ID. "0.0" indicates that the device is the root and there is no root
port.
91
