Bit Operand Search; Inserting And Deleting Instructions - Omron CPM2C-S100C Operation Manual

Programming Console Operations

8-2-11 Bit Operand Search

1,2,3...

8-2-12 Inserting and Deleting Instructions

176
5. The search will continue until an END instruction or the end of Program
Memory is reached. In this case, an END instruction was reached at ad-
dress 397.
SRCH
This operation is used to find occurrences of the specified operand bit in the
program and is possible in any mode.
RUN
OK OK
The ON/OFF status of any displayed bit will be shown if the PC is in RUN or
MONITOR mode.
1. Press the CLR Key to bring up the initial display.
2. Input the operand address. It is not necessary to input leading zeroes.
CONT F
SHIFT
#
3. Press the SRCH Key to begin the search.
SRCH
4. Press the SRCH Key to search for the next occurrence of the operand bit.
SRCH
5. The search will continue until an END instruction or the end of Program
Memory is reached. In this case, an END instruction was reached.
SRCH
This operation is used to insert or delete instructions from the program. It is
possible in PROGRAM mode only.
RUN
No No
Indicates the address
of END instruction.
00397SRCH
END (001)00.4KW
Indicates the amount used by the user
program in units of 0.1 Kwords.
MONITOR PROGRAM
OK
00000CONT SRCH
LD
5
00123CONT SRCH
LD
00255CONT SRCH
AND NOT
Indicates the address
of END instruction.
00397CONT SRCH
END (001)00.4KW
Indicates the amount used by the user
program in units of 0.1 Kwords.
MONITOR PROGRAM
OK
Section 8-2
00005
00005
00005
