Programming Console Operations
Incrementing and
Decrementing a Constant
1,2,3...

8-2-22 Hexadecimal, BCD Data Modification

!Caution Before changing the contents of I/O memory, be sure that the changes will not
1,2,3...
186
This operation can be used to increment and decrement an SV constant. It is
possible only when the SV has been entered as a constant.
1. Press the CLR Key to bring up the initial display.
2. Display the desired timer or counter.
TIM
SRCH
3. Press the Down Arrow, CHG, and then the EXT Key.
↓
CHG
The constant on the left is the old SV and the constant on the right will be-
come the new SV constant in step 5.
4. Press the Up and Down Arrow Keys to increment and decrement the con-
stant on the right. (In this case the SV is incremented once.)
5. Press the CLR Key twice to change the timer's SV to the new value.
CLR
This operation is used to change the BCD or hexadecimal value of a word
being monitored using the procedure described in 8-2-14 Bit, Digit, Word
Monitor. It is possible in MONITOR or PROGRAM mode only.
RUN
No OK
Words SR 253 to SR 255 cannot be changed.
cause equipment to operate unexpectedly or dangerously. In particular, take
care when changing the status of output bits. The PC continues to refresh I/O
bits even if the PC is in PROGRAM mode, so devices connected to output
points on the CPU Unit, Expansion Units, or Expansion I/O Units may operate
unexpectedly.
1. Monitor the status of the desired word according to the procedure de-
scribed in 8-2-14 Bit, Digit, Word Monitor. If two or more words are being
monitored, the desired word should be leftmost on the display.
(Word monitor)
2. Press the CHG Key to begin hexadecimal, BCD data modification.
3. Input the new PV and press the WRITE Key to change the PV.
00201SRCH
TIM
00201DATA ? U/D
T000 #0123 #0123
EXT
00201DATA ? U/D
T000 #0123 #0124
↓
00201 TIM DATA
CLR
MONITOR PROGRAM
OK
,
'
PRES VAL?
D0000 0119 ????
CHG
Section 8-2
000
#0124
