Pedestal Model
To install the alternate terminating resistors in the pedestal model, perform the following in
structions.
1.
Turn off the printer and disconnect the ac power cord.
2.
Turn the two captive screws at the top of the rear panel to unlock it. Lower the rear panel.
3.
Remove the 1K ohm resistor packs from the sockets at locations U1 and U3 on the I/O
PCBA located just inside the rear corner of the printer at the I/O connector as shown in
Figure 7-2.
4.
Plug the 220 ohm resistor pack into the socket at locations U1.
5.
Plug the 330 ohm resistor pack into the socket at U2.
6.
Raise and secure the rear panel
7.
Reconnect the ac power cord and turn the printer on.
7-10
Interfaces
