Horizontal Tab

ASCII Code:
Hex Code:
Purpose:
Expression:
Comment:
Example:
6-30
P-SERIES
N/A
N/A
Moves the logical printhead rightward to the next horizontal tab stop.
N/A
Power-on default horizontal tabs are set at .8-inch increments in the Serial
Matrix Mode. If there are no horizontal tabs set or the logical printhead is
located at the last character column, the code is ignored and no movement
occurs.
Horizontal tabs are stored as an absolute position; therefore character pitch
changes will not change horizontal tab positions. Refer to the Horizontal Tab
Set control code to set new tab positions.
Refer to the Horizontal Tab Set control code for a sample program of hori
zontal tab setting and accessing.
SERIAL MATRIX
HT
09
CHR$(9);
Programming
