FIRST DATA BYTE
BIT #
8
7
6
5
4
3
2
1 (LSB)
If a bit is set, the corresponding channel is assigned. If a bit is not set, the channel is not as
signed. Consequently, you must be aware of the binary equivalent of the data. For example,
assume 41 (hex) and 60 (hex) are the first two data bytes sent following the Start Load code.
41 hex = 01000001 binary
60 hex = 01100000 binary
This sequence results in channel 1 and channel 12 being assigned to line 1 of the form as shown
in Table 5-2. No other channels are assigned to line 1.
Each line on the form requires two bytes. For blank lines, the two bytes should not contain
channel assignments. That is, the data bytes sent in the load program corresponding to a blank
line on the form should not set any of bits 1 through 6.
This procedure can be continued for a maximum of 143 lines (286 DAVFU bytes). The DAVFU
ignores anything more than 286 bytes until the End Load code is received; if 572 bytes are re
ceived without an End Load code, the End Load code is forced" and the load routine is termi
nated.
FIRST DATA (Load) BYTE
BIT #
CHANNEL
NUMBER
8
7
6
5
4
3
2
1
Vertical Format Units
Table 5-1. DAVFU Channel Assignment
CHANNEL #
X (don't care)
X (don't care)
6
5
4
3
2
1
Table 5-2. Example DAVFU Date Bytes
HEX 41
BINARY
VALUE
X
X
X
X
6
0
5
0
4
0
3
0
2
0
1
1 - assign ch 1
(TOF)
X = don't care (1 or 0)
SECOND DATA BYTE
BIT #
CHANNEL #
8
X (don't care)
7
X (don't care)
6
12
5
11
4
10
3
9
2
8
1 (LSB)
7
SECOND DATA (Load) BYTE
HEX 60
BIT #
CHANNEL
NUMBER
8
X
7
X
6
12
5
11
4
10
3
9
2
8
1
7
BINARY
VALUE
X
X
1 - assign ch 12
0
0
0
0
0
5-3
