Line Spacing N/216 Inch - Printronix P6000L User's Reference Manual

Line Spacing n/216 Inch

ASCII Code:
Hex Code:
Purpose:
Expression:
where:
Comment:
Example:
Programming
P-SERIES
N/A
N/A
Specifies the line spacing at n/216-inch increments.
N/A
n = 1 to 255
When the n/216-inch line spacing control code is received, all line feeds fol
lowing will be at n/216-inch line spacing until a new line spacing is selected or
power is reset. The control code line spacing selection will override the con
trol panel line spacing setting and the message display will reflect the line
spacing in lines per inch. For a 50/216-inch line spacing, the message display
would reflect 4.3 lpi spacing.
The paper moves only in multiples of the current dot row spacing. If the dis
tance to move is other than a multiple of the current dot row spacing, the re
mainder is added to the next paper motion command.
The following example illustrates n/216-inch line spacing.
SERIAL MATRIX
ESC 3 n
1B 33 n
CHR$(27);"3";CHR$(n);
6-41
