2.

Operation

2. Operation

2.1 Functional elements and operating controls

2
1
Fig. 2 LogWIN 180 – 505
8
7
6
5
Fig. 3 LogWIN; open filling, lighting and ash door
Supplied as standard:
– Folder containing instructions
– Poker
– Scratcher
3
– Cleaning brush
– Spatula
– Ash pan
– Hanger (for installation on the wall
4
or Log- WIN side panel)
1 ........... Cladding door
2 ........... InfoWIN
3 ........... Boiler cover at rear – the cleaning cover
4 ........... Lever for cleaning heating surfaces
9
10
5 ........... Ash door
6 ........... Lighting door
11
7 ........... Filling door
8 ........... Hook catch for filling door
12
9 ........... Cladding flap – the MES modules, rating
10 ......... Cladding door switch
11 ......... Carbonisation gas extraction
12 ......... Filling chamber with hook-in plates
13 ......... Vertical grate
14 ......... Thermocontrol sensor
15 ......... Combustion chamber
13
16 ......... Ash chamber
17 ......... Ash pan
14
15
16
17
7
for coasting surfaces is underneath
plate, fuses and safety temperature
limiter are underneath
