2. Operation

2.6 Menu guide

Pressing the Menu button changes the menu display to the
Operator level, Service level, Information level or to MES
1
Module – Fig. 35.
Use the arrow buttons to select the Operator level, Service
level or Information level (Fig. 36) and confirm with the
Choose button – Fig. 37.
The menu item or sub-menu item is exited by pressing the
Back button (Fig. 38) or after a delay of 45 seconds.
Information!
Only trained service personnel may perform
system modifications on the Service level.
1 only displayed when an MESplus control is present and this has been adjusted by a trained service technician in the basic settings.
Boiler temperature
(Operating phases)
Info
Fig. 35
Operator level
Service level
Information level
MES Module
Fig. 36
Operator level
Service level
Information level
MES Module
Fig. 37
Operator level
Service level
Information level
MES Module
Fig. 38
15
42 °C
Menu
1
Choose Back
1
Choose Back
1
Choose Back
