ORDERING INFORMATION

BILL OF MATERIALS

Table 3.
Reference
Qty Designator Description
1 U1 ADP1974
2 CDL, CDH Bypass capacitors for logic DL and DH pins, 1000 pF,
10 V, 0805
2 RDL, RDH Signal integrity resistor, 20 Ω, 0805, ±1%
1 CVREG Bypass capacitor for internal LDO, 1 µF, 6.3 V, 0805
1 CVIN1 Input voltage bypass capacitor, 4.7 µF, 100 V, 10%, X7S,
1210
1 CVIN2 Input voltage bypass capacitor
1 CSYNC SYNC pin bypass capacitor, 0.1 µF, 6.3 V, 0805
1 RSYNC SYNC pin resistor, 1 kΩ, 0805, ±1%
1 RDT DT pin resistor, 10 kΩ, 0805, ±1%
1 RCL Current-limit offset sense resistor, 20 kΩ, 0805, ±1%
1 RS Current-limit set resistor
1 RSCFG Synchronization pin control resistor
3 CSCFG, CDMAX, SCFG, DMAX, and DT pin bypass capacitors, 47 pF, 50 V,
CDT 0805
1 RFREQ Frequency set resistor, 100 kΩ, 0805, ±1%
1 RDMAX Maximum duty cycle set resistor
1 CSS External soft start capacitor, 1000 pF
4 VIN, GND1, GND2, Test point loop connectors
CL
2 EN, MODE Headers, 0.100 inches, single, straight, 3-pin
8 VREG, DL, DH, PC test point, compact
DLR, DHR, COMP,
SYNC, FAULT
2 EN, MODE Connector, jumper, shorting, gold
1 Equivalent substitutions may be made for all passive components and connectors.
Alternatively, PBC36SAAN can be purchased and cut as necessary.
2

RELATED LINKS

Resource
ADP1974
AD8450
buck or boost, PWM controller
Description
Buck or boost, PWM controller for battery test solutions
Precision analog front end and controller for battery test/formation systems
Manufacturer
Analog Devices, Inc.
Kemet
Vishay Dale
TDK Corporation
TDK Corporation
Open
Kemet
Vishay Dale
Vishay Dale
Vishay Dale
Open
Open
Kemet
Vishay Dale
Open
Kemet
Aavid Thermalloy
Sullins Connector Solutions
Keystone Electronics
Sullins Connector Solutions
