PartsNeeded:
• #8x 3"(7.6 cm) w ood screws (longer screws may beneeded) (6)
• 2"x4"x32"(5cmx10cmx81cm) w ood board(s) (1or2)
• Custom wood overlay p anels--consult aqualified
cabinetmaker orcarpenter tomake thecustom wood panels.
See "Custom Wood Overlay Panels" formore information.
Panel kits--See " 36"Models o r42"French D oor M odels" for
panel kitinformation.
• Flexible, codes a pproved water supply t ubing, aferrule, a
union and a 1/4" (6.35 ram) c ompression fitting.
Parts Provided:
Slotted hex-head screw
W10141645 (21)
Hex-head blunt screw
W10142233 (4)
Phillips-head flat screw
8281251 (28)
Door Adjustment Pin
W10234194 5)
io r" }
Drawer Panel Bracket
W10203457 5)
Hex-head pointed screw
W10141189 (4)
Round-head screw
1163283 (24)
Door panel stud
W10129563 (4)
Door Stop Pin
W10234202 5)
%
Standard Integrated Grille
Bracket
W10182743-- Left (1)
W10182741--Right (1)
Fully Integrated Grille Bracket
W10260890-- Left (1)
W10260891 -- Right (1)
Panel top bracket
W10192849 (2)
RC Hinge Cover Trim
W10199873--42" SxS
W10199875--48" SxS
W10202875--36" BM (Right)
W10202510--42" FDBM (Right)
Panel templates
W10222281 --SxS
W10222279--BM
W10222283--Grille
Installation block
W10234156
Filler Board "L" Bracket
W10234199 5)
L,.
Top Grille Lower Trim
W10250961--36" BM (1)
W10250962--42" BM, SxS (1)
W10250963-- 48" SxS (1)
C
FC Hinge Cover Trim
W10199886--42"SxS
W10199888--48"SxS
W10202877--36" BM (Left)
W10202511--42"FDBM (Left)
Handle Side Door Trim
W10167367--SxS
W10188556-- BM (Left)
W10202604-- BM (Right)
W10202478-- FDBM (Right)
W10202480-- FDBM (Left)
6
