Specification

3-1 Overall System

RF Frequency Range
Audio Frequency Response

3-2 Receiver

Receiver Model
Frequency Stability
S/N Ratio
RF Sensitivity
Image Rejection
T.H.D. (1 KHz)
Display
Controls
Audio Output Level
Squelch
Operation Voltage
Output Connector
Dimension(m/m)
Oscillation Type
Channels
Band-width
Operation Range
US-902D pro
±0.005%
>100 dB
-107dBm (12DB S/N AD)
>60 dB
<0.6%@1 KHz
LCD
Power On/O , Volume Control,
Channel Up/Down, Squelch level
-12 dB
Pilot Tone & Noise Mute
12-18V DC, 600 mA
2 Balanced XLR socket
∅
1 Unbalanced 6.3mm Phone Jack (2.2 KΩ)
480mm(W)*45mm(H)*232mm(D)
494 MHz~870 MHz
PLL Synthesized Control OSC
16 Channels (US-902D Pro) / 64 Channel (US-903DC Pro)
50 Hz~18KHz
24 Mhz
100M
US-903DC pro
±0.005%
>100 dB
-107dBm (12DB S/N AD)
>60 dB
<0.6%@1 KHz
LCD
Power On/O , Volume Control,
Channel Up/Down, Squelch level
-12 dB
Pilot Tone & Noise Mute
12-18V DC, 1000 mA
2 Balanced XLR socket
1 Unbalanced
480mm(W)*45mm(H)*232mm(D)
∅
6.3mm Phone Jack (2.2 KΩ)
