Instruction Manual
US-936K/Mh-936K
Dual Channel Wide Bandwindth Wireless System
PROFESSIONAL CO., LTD
www.jts.com.tw
59508-047-01

Advertisement

Table of Contents
loading

  Related Manuals for JTS US-936K

  Summary of Contents for JTS US-936K

  • Page 1 Instruction Manual US-936K/Mh-936K Dual Channel Wide Bandwindth Wireless System PROFESSIONAL CO., LTD www.jts.com.tw 59508-047-01...
  • Page 2: Table Of Contents

    5. Connection 6. Operation 7. Recommendation 8. Important Notice Thank you for choosing the JTS wireless system. In order to obtain the best efficiency from the system, you are recommended to take a few minutes to read this instruction manual carefully.
  • Page 3: Important Caution

    1. Important Caution 3. Specification • 3-1 UHF PLL Dual Channel Diversity Receiver // US-936K Always makes all connections before plugging the unit into an AC power outlet. • Do not leave the device in a place neither with high temperature nor high humidity.
  • Page 4: Part Identification & Accessories

    4. Parts Identification & Accessories 4-1 UHF PLL Dual Channel Diversity Receiver // US-936K Front panel LCD Panel of the Receiver Power Switch : RF Level: display the strength of radio signal Lock on/off : AF Level: display the strength of audio signal...
  • Page 5: Uhf Pll Handheld Transmitter // Mh-936K

    4-2 UHF PLL Handheld Transmitter // Mh-936K LCD Display Rear panel Power and Mute Switch ▲:Up button: select the settings of transmitter Antenna ▼:Down button: select the settings of transmitter Balanced 6.3mm jack Output: for connection to the balanced input, e.g. of a mixer or an Set button: set the configuration of handheld transmitter amplifier Battery Tray...
  • Page 6: Connection

    AC outlet Press the Channel Select ▲, ▼ keys to select US-936K preset channels; a total of 225 sets (Step 2 of Figure 1) are available. A preset channel is displayed by the LED while the corresponded frequency is Caution displayed on LCD .
  • Page 7 6-2 Setting the Mh-936K Handheld transmitter 5. Squelch Key 1. Turn on the power Presss ▲, ▼ to adjust the squelch level between -10~+5; keeping the ▲ or ▼ keys pressed down (1) Press the Power switch to turn on the power to the makes the sensitivity adjustment faster,Presss ▲, ▼...
  • Page 8 3. Using preset channels: 4. Adjusting microphone sensitivity # When using preset channels, make settings as 3-1 and 3-2. (1) Press down the SET key for 2 seconds. 3-1 When a channel is displayed on LCD (2) The 3 digits on the left of the LCD begin to blink; press SET key four times to enter the sensitiv- (1) Press down the SET key for 2 seconds.
  • Page 9: Recommendation

    “open space” between the receiver and transmitter. (1) JTS offers wireless systems in a selection of bands that conform to the different government (2) Keep the devices away from the metal objects or any interference sources, at least 50 cm.
