CyberData 011030 Operation Manual page 38

2. On the Sensor Configuration page, enter values for the parameters indicated in
Web Page Item
Door Sensor Settings
Door Sensor Normally Closed
Door Open Timeout (in seconds)
Flash Button LED*
Activate Relay
Play Audio Locally
Play Audio Remotely
Dial Out Extension
Test Door Sensor
Intrusion Sensor Settings
Flash Button LED*
Activate Relay
Play Audio Locally
Play Audio Remotely
Dial Out Extension
Test Intrusion Sensor
Operations Guide
Table 2-9. Sensor Configuration Parameters
Description
Select the inactive state of the door sensors.
Select the number of seconds that you want to pass before
the door sensor is activated.
Check this box to flash the LED until the sensor is
deactivated (roughly 10 times/second).
Check this box to activate the relay until the sensor is
deactivated.
Check this box to loop an audio file out of the Intercom
speaker until the sensor is deactivated.
Check this box to call a preset extension and play a pre-
recorded audio file (once).
Enter the button dial-out extension number.
Use this button to test the door sensor.
Check this box to flash the LED until the sensor is
deactivated (roughly 10 times/second).
Check this box to activate the relay until the sensor is
deactivated.
Check this box to loop an audio file out of the Intercom
speaker until the sensor is deactivated.
Check this box to call a preset extension and play a pre-
recorded audio file (once).
Enter the button dial-out extension number.
Use this button to test the Intrusion sensor.
Link to the Home page.
Link to the Device Configuration page.
Link to the Networking page.
Link to go to the SIP Configuration page.
Link to the Sensor Configuration page.
Link to the Audio Configuration page.
930260D
Installing the VoIP Indoor Intercom
Parts List
Table 2-9.
CyberData Corporation
32
