CyberData 011030 Operation Manual page 16

Connector
J1
J2
J3
J4
J5
J6
J8
JP2
JP4
JP5
JP6
JP7
JP8
JP9
JP11
Operations Guide
Table 2-2. Connector Functions
Function
PoE Network Connection (RJ-45 ethernet)
Call Button - LED Interface
Terminal Block (see Figure
J-Tag (Factory only)
Microphone Interface
Speaker Interface
Console (Factory only)
Boot Mode (Factory only)
Reset (Factory only)
Watchdog Timer (Factory only)
Audio Enable (Factory only)
Network Mode (not installed) (Factory only)
Network Mode (not installed) (Factory only)
Network Mode (not installed) (Factory only)
RTFM (see Section 2.2.6, "RTFM Switch
930260D
2-4)
Jumper")
Installing the VoIP Indoor Intercom
Parts List
CyberData Corporation
10
