CyberData 011030 Operation Manual page 26

Web Page Item
Volume Settings
Speaker Volume
Microphone Gain
Relay Settings
Activate Relay with DTMF Code
DTMF Activation Code
DTMF Activation Duration (in seconds)
Activate Relay During Ring
Activate Relay on Button Press
Relay on Button Press Timeout (in seconds) Type the desired number of seconds for the timeout on the
Miscellaneous Settings
Auto-Answer Incoming Calls
Mute Microphone
Button Lit When Idle
Play Ringback Tone
Operations Guide
Table 2-5. Device Configuration Parameters
Description
Type the desired Intercom volume level into this field.
Type the desired microphone gain level into this field.
Check this box to use a DTMF code to activate the relay.
Type the desired DTMF activation code.
Type the desired DTMF activation duration (in seconds).
NOTE: A DTMF activation duration of 0 will toggle the
relay indefinitely or until the activation code is sent again
Check this box to activate the relay for as long as the
phone is ringing.
NOTE: When the phone is set to Auto Answer, it will not
ring and this option does nothing.
Check this box to activate the relay for a user-selectable
amount of time when the button is pressed.
relay after the button is pressed.
Check this box to have the Intercom automatically answer
incoming calls.
When Auto Answer is Off, the Intercom will play a
ringtone through the speaker until someone presses the
button.
When selected, the Intercom microphone is muted.
Check this box to have the Call Button light on when the
Intercom is idle.
Check this box to enable the Intercom to play a ringtone
while the remote device is ringing.
Link to the Home page.
Link to the Device Configuration page.
Link to the Networking page.
Link to go to the SIP Configuration page.
Link to the Sensor Configuration page.
Link to the Audio Configuration page.
930260D
Installing the VoIP Indoor Intercom
Parts List
CyberData Corporation
20
