Disassembly/Reassembly Procedures: Antenna
8.4

Antenna

This section explains how to attach and remove the antenna.
8.4.1 Attach Antenna
To attach the antenna:
With the radio turned off, turn the antenna clockwise to attach it to the radio.
8.4.2 Remove Antenna
To remove the antenna:
With the radio turned off, turn the antenna counter-clockwise to remove it from the radio.
Figure 8-2. Attaching the Antenna
Figure 8-3. Removing the Antenna
Sec 2: 8-5
