DEFINITY® Enterprise Communications Server Release 7
Console Operations 555-230-700
2 Understanding the Console Layout
Physical Layout of Your Console
Figure 9. Selector Console Area
Determining Extension Number Status
You can determine the status of an extension by pressing the two buttons
necessary to complete the extension and looking at the lamp to the left of the
appropriate DXS button.
If the lamp is dark, the extension is idle.
If the lamp is lighted, the extension is in use. You can still transfer a call if
system users have more than one line available. Ask your system manager
about the phones in your company.
If the extension is busy, you hear a busy tone.
Issue 4
June 1999
20
