9.

Data Sheet

9.1

Type

JUDO QUICKSOFT-UNO Softener
Abbreviated name: JQS-U
Order No.: 8200319
9.2

Technical specifications

– Maximum ambient temperature and wa-
ter temperature: 30°C (86°F)
– The water to be softened must con-
form to the European Drinking Water
Regulations!
– Threaded connection to DIN 2999.
Operating pressure Nominal pressure
2 – 7 bar
The nominal pressure denotes the pressure
class, according to which the Softener must
fulfil the requirements to DIN 19636. The
maximum operating pressure is lower, in or-
der to ensure the optimum function of the
Softener.
Data Sheet
PN 10
JUDO QUICKSOFT-UNO
Operating weight when filled
with salt
Shipping weight
Nominal flow rate up to
Flow pressure at nominal flow
rate at least
Pressure loss at nominal flow
rate
Short-term max. flow
Pipe connection
Nominal capacity
Capacity per kg regenerating
salt
Salt container capacity
Electrical connection
Max. power consumption
For further information, please
refer to the "Diagrams" chap-
ter.
approx.
90 kg
approx.
30 kg
1.2 m³/h
2 bar
0.7 bar
3.5 m³/h
1"
0.45 mol
5 mol
40 kg
230 V/
50 Hz
15 W
