EV-ADF411XSD1Z User Guide

QUICK START GUIDE

Follow these steps to evaluate the frequency synthesizer (ADF4110,
ADF4111, ADF4112, ADF4113, ADF4116, ADF4117, ADF4118,
ADF4106, ADF4107, ADF4153, ADF4154, ADF4156, or
ADF4157) after inserting all necessary components on the
board and ensuring that the on-board links are correct with
reference to Table 1:
1. Install the system development platform (SDP) drivers.
2. Install the Int-N or Frac-N PLL software.
3. Connect the SDP-S motherboard to the PC and to the
EV-ADF411XSD1Z.
4. Connect the power supplies to banana connectors (6 V
to 12 V).
5. Run the Int-N or Frac-N PLL software.
6. Select the SDP board and the frequency synthesizer in the
Select Device and Connection tab of the main window.
7. Click the Main Controls tab, and then update all registers.
8. Connect the spectrum analyzer to J2.
9. Measure the results.
