1.2

System Specifications

1.2.1 Main CPU Board

CPU
Socket LGA775 for Intel
Processor with FSB 533/800/1066 MHz
NOTE It doesn't support the processor with FSB 1333 MHz,
and it is not recommended to use Quad-Core CPU.
System Chipset
®
Intel Q965 + ICH8
BIOS
Phoenix-Award BIOS, 16Mbit with RPL/PXE LAN Boot ROM,
SmartView and Customer CMOS Backup
System Memory
Two 240-pin DDR2 DIMM maximum up to 4GB
L2 Cache
Integrated in CPU
Bus Clock
533/800/1066 MHz
Watchdog Timer
Up to 255 levels as Reset feature
1.2.2

I/O System

Standard I/O
Three serial ports with power, two RS-232 and one RS-
232/422/485
One PS/2 for Keyboard and Mouse Interface
Four USB Ports 2.0 compliant
Two IEEE1394a Ports
One DVI-I Output
Introduction
PANEL1153-841 User's Manual
®
TM TM
Core 2 Duo/Core Solo
3
