AXIOMTEK PANEL1153-841 User Manual

15” tft expandable intel core 2 duo industrial panel pc with 2 pci
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
PANEL1153-841
®
™
15" TFT Expandable Intel
Core
2 Duo
Industrial Panel PC with 2 PCI
User's Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PANEL1153-841 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for AXIOMTEK PANEL1153-841

Summary of Contents for AXIOMTEK PANEL1153-841

  • Page 1 PANEL1153-841 ® ™ 15” TFT Expandable Intel Core 2 Duo Industrial Panel PC with 2 PCI User’s Manual...
  • Page 2 AXIOMTEK does not warrant or assume any legal liability or responsibility for the accuracy, completeness or usefulness of any information in this document. AXIOMTEK does not make any commitment to update the information in this manual.

  • Page 3: Safety Approvals

    Safety Approvals CE Marking FCC Class A FCC Compliance This equipment has been tested in compliance with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are meant to provide reasonable protection against harmful interference in a residential installation.

  • Page 4: Safety Precautions

    Safety Precautions Before getting started, please read the following important safety precautions. The PANEL1153-841 Series does not come equipped with an operating system. An operating system must be loaded first before installing any software into the computer. Be sure to ground yourself to prevent static charge when installing the internal components.
  • Page 5 When handling boards and components, wear a wrist- grounding strap, available from most electronic component stores. Trademarks Acknowledgments AXIOMTEK is a trademark of AXIOMTEK Co., Ltd. IBM, PC/AT, PS/2, VGA are trademarks of International Business Machines Corporation. ® ®...

  • Page 6: Table Of Contents

    Table of Contents Disclaimers ......................ii Safety Approvals ....................iii Safety Precautions ....................iv C h a p t e r 1 Introduction ..............1 General Description................2 System Specifications ..............3 1.2.1 Main CPU Board ................3 1.2.2 I/O System..................3 1.2.3 System Specification...............
  • Page 7 System ................... 59 Touch Screen ................. 60 4.2.1 Specification................... 60 Driver Installation – Windows 2000/XP/Vista ....61 4.2.2 4.2.3 Driver Installation - DOS..........64 A p p e n d i x Power Supply Specification........67...
  • Page 8 MEMO viii...

  • Page 9: Chapter 1 Introduction

    PANEL1153-841 User’s Manual C h a p t e r 1 Introduction This chapter contains general information and detailed specifications of the PANEL1153-841. Chapter 1 includes the following sections: General Description System Specification Dimensions Front View & I/O Outlets Package List...

  • Page 10: General Description

    PANEL1153-841 User’s Manual General Description The PANEL1153-841 is a 15” Industrial panel PC which features ® ™ ® Intel Core 2 Duo processor and Intel Q965 chipset to provide powerful computing performance. This panel PC also offers the expansion ability with two PCI slots. It adopts built-in speaker and WLAN module for wireless connectivity.

  • Page 11: System Specifications

    PANEL1153-841 User’s Manual System Specifications 1.2.1 Main CPU Board ® Socket LGA775 for Intel Core 2 Duo/Core Solo Processor with FSB 533/800/1066 MHz NOTE It doesn’t support the processor with FSB 1333 MHz, and it is not recommended to use Quad-Core CPU.

  • Page 12: System Specification

    PANEL1153-841 User’s Manual Ethernet First port with i82566DM Gigabit Ethernet PHY, Second port with RTL8111B for Gigabit/Fast Ethernet Audio HD Audio for two channels output MIC-In, Line-Out Storage Four SATA-300 interface Box-Header One 26-pin for shared LPT/FDD(optional) Expansion Slot Two 32-bit PCI Master slots 1.2.3...

  • Page 13: Dimensions

    PANEL1153-841 User’s Manual Heat Dispensing Design Two slots for PCI expansion Net Weight 13 Kgs Dimension (Main Body Size) 420mm (16.51”)(W) x 150mm (9.14”)(D) x 335mm (13.19”)(H) Operation Temperature 0℃to 40℃; Relative Humidity 50% Relative Humidity 10% to 85% @ 40℃, Non-Condensing Altitude 10,000 ft.

  • Page 15: Front View And I/O Outlets

    PANEL1153-841 User’s Manual Front View and I/O Outlets 1.4.1 Front View Please refer to the following illustration for features and controls of the PANEL1153-841 front bezel. Function SEL+ SEL- Backlight ON/OFF Introduction...

  • Page 16: I/O Outlets

    PANEL1153-841 User’s Manual 1.4.2 I/O Outlets The following figure shows the I/O locations of the PANEL1153-841. Connector Connector COM1 COM 2 & COM 3 DVI-I Power Switch Giga LAN x 2 AC power IEEE 1394a x 2 PCI slots x 2 USB v2.0 x 4...

  • Page 17: Package List

    PANEL1153-841 User’s Manual Package List The package bundled with your PANEL1153-841 should contain the following items: P1153-841 x 1 AC power cord x 1 Panel mount kit x 7 Driver CDx1 LGA 775 CPU Cooler x 1 DVI TO VGA Adaptor x 1 PS/2 Splitter –...
  • Page 18 PANEL1153-841 User’s Manual MEMO Introduction...

  • Page 19: Chapter 2 Hardware Installation

    PANEL1153-841 User’s Manual C h a p t e r 2 Hardware Installation The PANEL1153-841 is convenient for your various hardware configurations in flexible ways, such as CPU (Central Processing Unit), HDD (Hard Disk Drive), Memory Module (DRAM), CD-ROM, Add-On card, and more. The chapter 2 will show you how to install the hardware.
  • Page 20 PANEL1153-841 User’s Manual Step 1 Unscrew screws to remove the rear chassis. Step 2 Remove the riser card fix kit. Hardware Installation...
  • Page 21 PANEL1153-841 User’s Manual Step 3 Install the CPU and DDR DRAM in the PANEL1153-841. DRAM Hardware Installation...

  • Page 22: Installing The The Hard Disk Drive

    HDD. The system offers users two 3.5” Hard Disk Drives for installation. If you want to install one or two 2.5” HDD, the PANEL1153-841 also provides the 3.5” to 2.5” drive holder to meet your requirement. Please follow the steps: Note The hardware limitation is the 2.5”...
  • Page 23 PANEL1153-841 User’s Manual Step 4 The installation is completed. Installing Dual 3.5” HDD If installing the dual 3.5” HDD, please follow the steps: Step 1 Change HDD bracket from 3.5” to dual 3.5”. Hardware Installation...
  • Page 24 PANEL1153-841 User’s Manual Step 2 Fix the Hard Disk to the HDD bracket to complete the installation. Hardware Installation...
  • Page 25 PANEL1153-841 User’s Manual Note When installing Dual 3.5” HDD, users must install a fan to decrease system heat. Installation step as following: Installing fan when using dual 3.5” HDD Step 1 Screw the fan to the right side of cover.
  • Page 26 PANEL1153-841 User’s Manual (1-2) (1-3) Step 2 Connect power cable of fan to 3 pin fan connector (CN3) in motherboard. Hardware Installation...
  • Page 27 PANEL1153-841 User’s Manual If installing the 2.5” HDD, please follow the steps: Step 1 Set the 2.5” HDD in the HDD bracket kit. Step 2 Install the HDD in the PANEL1153-841. Hardware Installation...

  • Page 28: Cd-Rom Installation

    PANEL1153-841 User’s Manual CD-ROM Installation The PANEL1153-841 offers a convenient drive bay module for users to install CD-ROM. When installing the CD-ROM, refer to the following instructions and illustration: Step 1 Unscrew screws to remove the rear chassis. Step 2 Remove the riser card fix kit.

  • Page 29: Add-On Card Installation

    PANEL1153-841 User’s Manual Add-on Card Installation The PANEL1153-841 provides a riser card for PCI slots expansion. The riser card assembly can accommodate both half-size expansion cards. To install the riser card, refer to the following figure and instructions below: Step 1 Remove the rear chassis.
  • Page 30 PANEL1153-841 User’s Manual Step 4 Insert the add-on card in the socket firmly until it is completely seated. Hardware Installation...

  • Page 31: Serial Port Interface

    PANEL1153-841 User’s Manual Serial Port Interface The PANEL1153-841 has three onboard serial ports, COM1, COM2, and COM3. COM1 is RS-232(default)/422/485 Port Connector while COM2 and COM3 are RS-232 Port Connectors. The connector, COM1, COM2, COM3 are DB-9 connector, and the following table shows the pin assignments of this connector.
  • Page 32 PANEL1153-841 User’s Manual Ground Signal Signal Ground TXC+ TXC- CRT-RED CRT-GREEN CRT-BLUE CRT-HSYNC VGAGND 8 C1 NOTE It doesn’t support display in LCD and DVI-D simultaneously. DVI-D is only available after booting up in Windows XP. Hardware Installation...

  • Page 33: Ethernet

    PANEL1153-841 User’s Manual Ethernet The PANEL1153-841 provides a NE2000 compatible Ethernet (RJ-45) interfaces. For network connection, just plug in one cable end of the system’s 10/100/1000-Base-T Hub into a standard RJ-45 connector. Please refer to detailed pin assignment list below:...

  • Page 34: Mountings Way - Panel

    PANEL1153-841 User’s Manual Mountings Way – Panel There is one application option for the PANEL1153-841, Panel mounting. Panel – Mount Kit Assembley The PANEL1153-841 is designed for panel mount application. To mount the PANEL1153-841, the standard set of mounting kit (included in the system packaging) is needed.

  • Page 35: Chapter 3 Phoenix-Award Bios Utility

    PANEL1153-841 User’s Manual C h a p t e r 3 Phoenix-Award BIOS Utility The Phoenix-Award BIOS provides users with a built-in Setup program to modify basic system configuration. All configured parameters are stored in a battery-backed-up RAM (CMOS RAM) to save the Setup information whenever the power is turned off.

  • Page 36: Control Keys

    PANEL1153-841 User’s Manual Control Keys Move cursor to the previous item Up arrow Move cursor to the next item Down arrow Move cursor to the item on the left hand Left arrow Move to the item in the right hand...

  • Page 37: The Main Menu

    PANEL1153-841 User’s Manual The Main Menu Once you enter the Award BIOS CMOS Setup Utility, the Main Menu appears on the screen. In the Main Menu, there are several Setup functions and a couple of Exit options for your selection. Use arrow keys to select the Setup Page you intend to configure then press <Enter>...

  • Page 38: Standard Cmos Setup Menu

    PANEL1153-841 User’s Manual Standard CMOS Setup Menu The Standard CMOS Setup Menu displays basic information about your system. Use arrow keys to highlight each item, and use <PgUp> or <PgDn> key to select the value you want in each item.
  • Page 39 PANEL1153-841 User’s Manual IDE Primary Master/Primary Slave These items identify the types of each IDE channel installed in the computer. There are 45 predefined types (Type 1 to Type 45) and 2 user’s definable types (Type User) for Enhanced IDE BIOS.

  • Page 40: Advanced Bios Features

    PANEL1153-841 User’s Manual Press <Esc> to return to the Main Menu page. Advanced BIOS Features This section allows you to configure and improve your system, to set up some system features according to your preference. Phoenix-Award BIOS Utility...
  • Page 41 PANEL1153-841 User’s Manual CPU Feature Scroll to this item and press <Enter> to view the CPU Feature sub menu. Hard Disk Boot Priority Scroll to this item and press <Enter> to view the sub menu to decide the disk boot priority.
  • Page 42 PANEL1153-841 User’s Manual Virus Warning This option flashes on the screen. During and after the system boot up, any attempt to write to the boot sector or partition table of the hard disk drive will halt the system with the following message. You can run an anti-virus program to locate the problem.
  • Page 43 PANEL1153-841 User’s Manual First/Second/Third Boot Device These items let you select the 1st, 2nd, and 3rd devices that the system will search for during its boot-up sequence. The wide range of selection includes Floppy, LS120, ZIP100, HDD0~3, SCSI, and CDROM.
  • Page 44 PANEL1153-841 User’s Manual Typematic Rate (Chars/Sec) This option refers to character numbers typed per second by the keyboard. The default value is “6”. 6 characters per second 8 characters per second 10 characters per second 12 characters per second 15 characters per second...
  • Page 45 PANEL1153-841 User’s Manual APIC Mode Use this item to enable or disable APIC (Advanced Programmable Interrupt Controller) mode that provides symmetric multi- processing (SMP) for systems. MPS Version Control For OS This item specifies the version of the Multiprocessor Specification (MPS).

  • Page 46: Advanced Chipset Features

    PANEL1153-841 User’s Manual Advanced Chipset Features This section contains completely optimized chipset’s features on the board that you are strongly recommended to leave all items on this page at their default values unless you are very familiar with the technical specifications of your system hardware.
  • Page 47 PANEL1153-841 User’s Manual PCI Express Root Port Func Scroll to this item and press <Enter> to view the sub menu to decide the PCI Express Port. Press <Esc> to return to the Advanced Chipset Featurs page. *** VGA Setting *** PEG/Onchip VGA Control Use this item to choose the primary display card.

  • Page 48: Integrated Peripherals

    PANEL1153-841 User’s Manual Boot Display This item is for Intel define ADD card only. Press <Esc> to return to the Main Menu page. Integrated Peripherals This section allows you to configure your SuperIO Device, IDE Function and Onboard Device. Phoenix-Award BIOS Utility...
  • Page 49 PANEL1153-841 User’s Manual OnChip IDE Device Scroll to this item and press <Enter> to view the sub menu OnChip IDE Device. IDE HDD Block Mode Block mode is also called block transfer, multiple commands, or multiple sector read/write. If your IDE hard drive supports...
  • Page 50 PANEL1153-841 User’s Manual Master/Slave PIO items on the menu. IDE Master/Slave PIO The four IDE PIO (Programmed Input/Output) fields let you set a PIO mode (0-4) for each of the four IDE devices that the onboard IDE interface supports. Modes 0 to 4 provide successively increased performance.
  • Page 51 PANEL1153-841 User’s Manual Super IO Device Scroll to this item and press <Enter> to view the sub menu Super IO Device. Onboard FDC Controller Select Enabled if your system has a floppy disk controller (FDC) installed on the system board and you wish to use it.
  • Page 52 PANEL1153-841 User’s Manual Parallel Port Mode Select an operating mode for the onboard parallel (printer) port. Select Normal unless your hardware and software require one of the other modes offered in this field. The options available are EPP1.9, ECP, SPP, ECPEPP1.7, EPP1.7.

  • Page 53: Power Management Setup

    PANEL1153-841 User’s Manual Power Management Setup The Power Management Setup allows you to save energy of your system effectively. It will shut down the hard disk and turn OFF video display after a period of inactivity. Phoenix-Award BIOS Utility...
  • Page 54 PANEL1153-841 User’s Manual ACPI Function This item allows you to enable/disable the Advanced Configuration and Power Management (ACPI). The function is always “Enabled”. ACPI Suspend Type This item specifies the power saving modes for ACPI function. If your operating system supports ACPI, such as Windows 98SE,...
  • Page 55 PANEL1153-841 User’s Manual to restore the system when a “wake up” event occurs. Run VGABIOS if S3 Resume When this item is set Auto, the system will run VGA BIOS if it is reaumed from the S3 state. Power Management This option allows you to select the type (or degree) of power saving for Doze, Standby, and Suspend modes.
  • Page 56 PANEL1153-841 User’s Manual connect the fax/modem to the board Wake On Modem connector for working this feature. Suspend Mode After the selected period of system inactivity (1 minute to 1 hour), all devices except the CPU shut off. The default value is “Disabled”.
  • Page 57 PANEL1153-841 User’s Manual ** Reload Global Timer Events ** Global Timer (power management) events can prevent the system from entering a power saving mode or can awaken the system from such a mode. Primary/Secondary IDE 0/1 Use this item to configure the IDE devices monitored by the system.

  • Page 58: Pnp/Pci Configuration Setup

    PANEL1153-841 User’s Manual 3.10 PnP/PCI Configuration Setup This section describes configuring the PCI bus system. PCI, or Personal Computer Interconnect, is a system which allows I/O devices to operate at speeds nearing the speed the CPU itself uses when communicating with its own special components. This section covers some very technical items and it is strongly recommended that only experienced users should make any changes to the default settings.
  • Page 59 PANEL1153-841 User’s Manual interrupt to one of the following types in accordance with the type of devices using the interrupt: 1. Legacy ISA Devices compliant with the original PC AT bus specification, requiring a specific interrupt (such as IRQ4 for serial port PCI/ISA PnP Devices compliant with the Plug and Play standard, whether designed for PCI or ISA bus architecture.

  • Page 60: Pc Health Status

    PANEL1153-841 User’s Manual 3.11 PC Health Status This section supports hardware monitering that lets you monitor those parameters for critical voltages, temperatures and fan speed of the board. Shutdown Temperature It helps you set the maximum temperature they system can reach before powering down.

  • Page 61: Frequency/Voltage Control

    PANEL1153-841 User’s Manual 3.12 Frequency/Voltage Control This section is to control the CPU frequency and Supply Voltage, DIMM OverVoltage and AGP voltage. CPU Clock Ratio Use this item to select the CPU’s frequency. Auto Detect PCI Clk The enabled item can automatically disable the clock source for a PCI slot without a module, to reduce EMI (ElectroMagnetic Interference).

  • Page 62: Load Optimized Defaults

    PANEL1153-841 User’s Manual 3.13 Load Optimized Defaults This option allows you to load the default values to your system configuration. These default settings are optimal and enable all high performance features. To load SETUP defaults value to CMOS SRAM, enter “Y”. If not, enter “N”.

  • Page 63: Set Supervisor/User Password

    PANEL1153-841 User’s Manual 3.14 Set Supervisor/User Password You can set either supervisor or user password, or both of then. The differences between are: Supervisor password: can enter and change the options of the setup menus. User password: just can enter but do not have the right to change the options of the setup menus.

  • Page 64: Save & Exit Setup

    PANEL1153-841 User’s Manual 3.15 Save & Exit Setup This allows you to determine whether or not to accept the modifications. Typing “Y” quits the setup utility and saves all changes into the CMOS memory. Typing “N” brigs you back to Setup utility.

  • Page 65: Exit Without Saving

    PANEL1153-841 User’s Manual 3.16 Exit Without Saving Select this option to exit the Setup utility without saving the changes you have made in this session. Typing “Y” will quit the Setup utility without saving the modifications. Typing “N” will return you to Setup utility.
  • Page 66 PANEL1153-841 User’s Manual MEMO Phoenix-Award BIOS Utility...

  • Page 67: Chapter 4 Driver Installation

    C h a p t e r 4 Driver Installation System PANEL1153-841 supports Windows 2000/XP/Vista. To facilitate the installation of the system driver, please carefully read the instructions in this chapter before start installing. 1. Here is the path for the system driver: Panel series\P1153-841\Driver 2.

  • Page 68: Touch Screen

    PANEL1153-841 User’s Manual Touch Screen 4.2.1 Specification Touch Screen 5-wire Analog Resistive type Touch Screen Controller DMC9000 (10-bit A/D converter inside) Communications RS-232 Baud Rate 19200 and 9600 baud selection Resolution 2048 x 2048 Mode Selection PnP or non-PnP Power Input...

  • Page 69: Driver Installation - Windows 2000/Xp/Vista

    PANEL1153-841 User’s Manual 4.2.2 Driver Installation – Windows 2000/XP/Vista The PANEL1153-841 provides a driver of the touch screen that users can install it under operating system Windows 2000/XP/Vista. To facilitate this touch screen driver installation, users should read the instructions in this chapter carefully before start the installation.
  • Page 70 PANEL1153-841 User’s Manual Select the “Standard Calibrate” tab. Driver Installation...
  • Page 71 PANEL1153-841 User’s Manual Calibration: To adjust the display with touch panel, click “Calibration” and follow the calibrate point to do calibration; there are five points on screen for calibration. Press OK. Driver Installation...

  • Page 72: Driver Installation - Dos

    PANEL1153-841 User’s Manual 4.2.3 Driver Installation - DOS Using “INSTALL.EXE” Utility to Install PenMount Software Driver Insert Driver CD and select the Panel series\P1153- 841\Driver\Step5 - Touch\Driver\DOS\Install.exe Press ENTER key to install the drivers to drive C or use keyboard to key-in the hard disc drive that you plan to install the driver.
  • Page 73 PANEL1153-841 User’s Manual C:\PENMOUNT\PMDETECT -N5 -N9 Do Calibration 1. To adjust the touch screen mapping properly to display screen, use PM.BAT (C:\PENMOUNT\PM) to do calibration. Choose “1” DO CALIBRATION (adjust screen mapping). 2. The message pops out to ask if you select the video mode number.
  • Page 74 PANEL1153-841 User’s Manual MEMO Driver Installation...

  • Page 75: Appendix Power Supply Specification

    PANEL1153-841 User’s Manual A p p e n d i x Power Supply Specification Power Supply FSP250-50GUB (250W, AC100~240V Input) Electrical Requirements OUTPUT ELECTRICAL REQUIREMENTS The subject power supply will meet all electrical specifications below, over the full operation temperature range and dynamic load regulation.
  • Page 76 PANEL1153-841 User’s Manual LOAD CAPACITY SPECIFICATIONS The cross regulation defined as follows, the voltage regulation limits DC include DC Output ripple & noise. LOAD +3.3V +12V -12V +5VSB Condition_1 Condition_2 0.5A 0.3A 0.1A Condition_3 0.5A 0.8A 0.1A Condition_4 0.1A 0.1A Condition_5 0.1A...

  • Page 77: Environmental Requirements

    PANEL1153-841 User’s Manual SHORT CIRCUIT PROTECTION Output short circuit is defined to be a short circuit load of less than 0.1 ohm. In the event of an output short circuit condition on +3.3V, +5V or +12V output, the power supply will shutdown and latch off. The power supply...
  • Page 78 PANEL1153-841 User’s Manual Vibration: 0.25G, 10~250Hz Shock: -40G, 11mSec for Storage, -10G, 11mSec for operating Reliability The power supply reliability, when calculated by MIL- HDBK;latest revision, are exceed 100,000 hours with all output at maximum load and an ambient temperature of 25℃.
