PANEL1153-841 User's Manual
2.2

Installing the the Hard Disk Drive

The PANEL1153-841 offers a convenient drive bay module for users
to install HDD. The system offers users two 3.5" Hard Disk Drives for
installation. If you want to install one or two 2.5" HDD, the
PANEL1153-841 also provides the 3.5" to 2.5" drive holder to meet
your requirement. Please follow the steps:
Note The hardware limitation is the 2.5" HDD and 3.5" HDD
CAN NOT exist simultaneously.
Step 1 Unscrew screws to remove the rear chassis.
Step 2 Remove the riser card fix kit.
Step 3 Unscrew 4 screws from the HDD drive bracket, and take out
HDD bracket kit to install 3.5" HDD.
14 Hardware Installation
