Heat Dispensing Design
Two slots for PCI expansion
Net Weight
13 Kgs
Dimension (Main Body Size)
420mm (16.51")(W) x 150mm (9.14")(D) x 335mm
(13.19")(H)
Operation Temperature
0℃to 40℃; Relative Humidity 50%
Relative Humidity
10% to 85% @ 40℃, Non-Condensing
Altitude
10,000 ft. (3,000 meters)
Vibration (Operating)
5 to 500 Hz, 1 G random
Shock (Operating)
10 G peak acceleration (11 msec. duration)
NOTE All specifications and images are subject to change
without notice.
1.3

Dimensions

This diagram shows you dimensions and outlines of the PANEL1153-
841.
