DP2K C-series
Installation manual
For DP2K-12C, DP2K-15C, DP2K-20C
R5905050/04
10/07/2012

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DP2K-12C and is the answer not in the manual?

Questions and answers

Related Manuals for Barco DP2K-12C

Summary of Contents for Barco DP2K-12C

  • Page 1 DP2K C-series Installation manual For DP2K-12C, DP2K-15C, DP2K-20C R5905050/04 10/07/2012...
  • Page 2 Barco Inc. Media and Entertainment Division 11101 Trade Center Drive, Rancho Cordova, California 95670, USA Phone: +1 916 859-2500 Fax: +1 916 859-2515 Support: www.Barco.com/esupport Visit us at the web: www.barco.com Barco nv Entertainment Division Noordlaan 5, B-8520 Kuurne Phone: +32 56.36.82.11 Fax: +32 56.36.883.86...

  • Page 3: Software License Agreement

    GNU-GPL code If you would like a copy of the GPL source code contained in this product shipped to you on CD, please contact Barco. The cost of preparing and mailing a CD will be charged.
  • Page 4 For more information about recycling of this product, please contact your local city office or your municipal waste disposal service. For details, please visit the Barco website at: http://www.barco.com/en/AboutBarco/weee Information for China ROHS compliance Table of toxic and hazardous substances/elements and their content, as required by China’s management methods for controlling pollution...
  • Page 5 Projector 零部件名稱 有毒有害物質或元素 铅（Pb） 镉（Cd 多 溴 二 苯 醚 汞（Hg） 六价铬（Cr6+） 多溴联苯（PBB） （PBDE） 外部信号连接线 風扇 散熱模組 (金屬部 分) 讀卡器 喇叭 (電路板組件 除外) 附電池遙控器 (電 路板組件除外) *： 电路板组件包括印刷电路板及其构成的零部件，如电阻、电容、集成电路、连接器等 ○：表示该有毒有害物质在该部件所有均质材料中的含量均在《电子信息产品中有毒有害物质的限量要求标准》规定的限量要求以下 ×：表示该有毒有害物质至少在该部件的某一均质材料中的含量超出《电子信息产品中有毒有害物质的限量要求标准》规定的限量要求；但 是上表中打“×”的部件，其含量超出是因为目前业界还没有成熟的可替代的技术，且符合歐盟RoHS指令的排外條款及電池指令...

  • Page 7: Table Of Contents

    Table of contents TABLE OF CONTENTS 1. Safety ....................... .. 3 General considerations.
  • Page 8 13.1 Specifications of a DP2K-12C projector ........

  • Page 9: Safety

    • Before operating this equipment please read this manual thoroughly and retain it for future reference. • Installation and preliminary adjustments should be performed by qualified Barco personnel or by authorized Barco service deal- ers. • All warnings on the projector and in the documentation manuals should be adhered to.

  • Page 10: Important Safety Instructions

    1. Safety Product article number Product serial number Dealer Important safety instructions To prevent the risk of electrical shock • This projector should be operated from an AC power source. Ensure that the mains voltage and capacity matches the projector electrical ratings.
  • Page 11 fire extinguishers. Never use water on an electrical fire. Always have service performed on this projector by authorized Barco service personnel. Always insist on genuine Barco replacement parts. Never use non-Barco replacement parts as they may degrade the safety of this projector.
  • Page 12 If the product exhibits a distinct change in performance, indicating a need for service. • Replacement parts: When replacement parts are required, be sure the service technician has used original Barco replacement parts or authorized replacement parts which have the same characteristics as the Barco original part. Unauthorized substitu- tions may result in degraded performance and reliability, fire, electric shock or other hazards.

  • Page 13: General

    • DP2K-20C Barco provides a guarantee relating to perfect manufacturing as part of the legally stipulated terms of guar- antee. Observing the specification mentioned in this chapter is critical for projector performance. Neglecting this can result in loss of warranty.

  • Page 14: Projector Weight

    ±102 kg (±225 lb.) Barco offers a pedestal for the DP2K C-series projector. This universal pedestal allows a solid and easy setup of the projector. The universal pedestal has a separate compartment to install the UPS unit for the DP2K C-series projector.
  • Page 15 2. General Image 2-1 2. Remove the smaller carton box (reference 1) as illustrated. Note: The smaller carton box contains the manual. Image 2-2 3. Remove the carton box and the foam around the projector. See image 2-2. Note: The projector is still attached to a wooden plate, which is secured to the below pallet. 4.

  • Page 16: Initial Inspection

    Save all packing material until the inspection is completed. If damage is found, file claim with carrier immediately. The Barco Sales and Service office should be notified as soon as possible.

  • Page 17: Installation Process Overview

    This check should confirm that there are no broken knobs or connectors, that the cabinet and panel surfaces are free of dents and scratches, and that the operating panel is not scratched or cracked. The Barco Sales and Service office should be notified as soon as possible if this is not the case.
  • Page 18 42, to adjust the Scheimpflug and see chapter "Convergence", page 87 to adjust the convergence of the light path. 12.Registration of the projector. The DP2K C-series projector is DCI compliant and should be registered by Barco. Therefore, the digital certificate inside the projector will be used to secure encryption key communication between the projector and the rest of the theatre system (server and theatre management system).

  • Page 19: Physical Installation

    Positioning at port window Barco offers a pedestal for the DP2K C-series projector. This universal pedestal allows a solid and easy setup of the projector. The universal pedestal has a separate compartment to install the UPS unit (if available) for the DP2K C-series projector.

  • Page 20: Projector Centering

    3. Physical installation Projector centering 1. If the projector is standalone in front of the port window, center the projector with the theatre screen (see ref A image 3-2). 2. If a film projector is already present (projector will be off-center), try to optimize aim (see ref B image 3-2). Note: Unlike film projectors, it is best to keep the projector lens surface as parallel to the screen as possible, even if it is significantly above the screen center.

  • Page 21: Installation Of The Exhaust System

    Inclined screen Image 3-4 Projector tilting Barco offers a pedestal for the DP2K C-series projector. This universal pedestal allows you to easily tilt the projector forward up to 6°. Installation of the exhaust system THE USE OF AN EXHAUST SYSTEM IS MANDATORY ! About Exhaust The exhaust stack of the projector head is designed to fit a 201 mm (7.91 inch) diameter duct.

  • Page 22: Connecting The Projector With The Power Net

    3. Physical installation Image 3-5 Exhaust system Ensure good condition of the lamp house blower. Keep the blower inlet clean for unrestricted air flow. To ensure maximum lamp life, operate the lamp house blower and the exhaust system for at least ten minutes after extinguishing the lamp.
  • Page 23 3. Physical installation Necessary parts • Two cable ties. • Certified AC power supply cord 4.0 mm², 10AWG, min. 300V. How to connect the main AC power with the DP2K C-series projector projector? 1. Remove the rear cover and lamp cover of the projector. 2.

  • Page 24: Power Loop Through To The Projector Electronics

    3. Physical installation Image 3-8 5. Reinstall the cover of the main AC compartment. Image 3-9 6. Reinstall the rear cover and lamp cover of the projector. Power loop through to the projector electronics This procedure explains how to provide the projector electronics with power in case no UPS unit is used. Note that the projector is by default configured for use without UPS.

  • Page 25: Connecting A Ups With The Projector Electronics

    2. Plug in the short power cable (reference 4) which was delivered with the projector. Warning: Always use the Barco short power cable which is delivered with the projector. 3. Secure both plugs of the short power cable with a fixation plate. Use two thumbscrews (reference 5) per fixation plate. Note that the smallest fixation plate (reference 7) has to be used upon the upper socket (INLET, reference 2).
  • Page 26 3. Physical installation How to connect a UPS unit with the projector electronics? 1. Install the UPS unit according to the instructions of the manufacturer and the local regulations. 2. Connect the power output cord (reference 1) from the UPS unit with the UPS INLET socket of the projector (upper socket). 3.

  • Page 27: Lamp & Lamp House

    4. Lamp & Lamp House 4. LAMP & LAMP HOUSE About this chapter This chapter enumerates all the supported xenon lamps for the DP2K C-series projector and how to replace the xenon lamp in the lamp house. Also included is the procedure to reset the lamp parameters, which is required after a xenon lamp replacement, and the procedure to realign the lamp in its reflector for optimal performance.
  • Page 28 4. Lamp & Lamp House Image 4-1 Lamp house. Xenon lamp. The xenon lamp is packed in a protective container or wrapped in a protective cloth. Never remove this protective container or protective cloth without wearing adequate protective clothing (face shield, clean leather glovers, welder’s jacket). Image 4-2 Left: Xenon lamp in protective container.

  • Page 29: Removal Of The Lamp House

    4. Lamp & Lamp House Supported xenon bulb lamps (without lamp house) Lamp Type Order info DP2K-12C DP2K-15C DP2K-20C Osram xenon lamp of 4 kW 4kW DHP R9855937 Osram xenon lamp of 3 kW 3kW DHP R9855938 Osram xenon lamp of 2 kW...

  • Page 30: Removal Of The Xenon Lamp

    4. Lamp & Lamp House Image 4-4 Release lamp house 4. Take the lamp house by the handles and pull it out of the projector. Caution: Be aware of the weight of the lamp assembly. Take the necessary precautions to avoid personal injury. Image 4-5 Remove lamp house 5.
  • Page 31 4. Lamp & Lamp House AUTION Xenon compact arc lamps are highly pressurized. When ignited, the normal operating temperature of the bulb increases the pressure to a level at which the bulb may explode if not handled in strict accordance to the manufacturer’s instructions.
  • Page 32 4. Lamp & Lamp House Image 4-7 3. Release the four retaining thumbscrews of the UV blocker assembly as illustrated. Make sure that the UV blocker assembly remains in its position while releasing the screws. Image 4-8 4. Support the xenon lamp inside the Lamp House with one hand while removing the UV blocker assembly from the Lamp House. Note that some xenon lamps are installed with an anode adaptation bushing.
  • Page 33 4. Lamp & Lamp House Image 4-10 6. Place the xenon lamp into a protective container or wrap a protective cloth around the xenon lamp prior to proceed with this procedure. 7. Remove the anode wire lug from the anode socket. Use for that two open end wrenches of 17 mm. Hold one nut (reference 7) with one wrench while releasing the other nut (reference 4) with the other wrench.

  • Page 34: Installation Of The Xenon Lamp

    4. Lamp & Lamp House AUTION Expired xenon lamps. Dispose of expired bulbs that are beyond warranty in the following manner: wrap the bulb tightly in several layers of canvas or heavy cloth. Place it on hard surface and shatter the envelope with a sharp hammer blow. DO NOT place a non shattered bulb in any ordinary refuse container.
  • Page 35 4. Lamp & Lamp House Image 4-13 Remove UV blocker and side cover 2. Install the lamp cathode adaptor (reference 1) upon the xenon lamp (reference 3) as illustrated. Tighten the adapter fixation screw (reference 2) with a torque of 2,5 Nm (1.84 lbf*ft). Use for that a torque wrench with a 5 mm Allen socket. Make sure that there is full contact between the cathode adapter and the lamp base.
  • Page 36 4. Lamp & Lamp House 9 Nm Image 4-15 Anode lug installation 4. Remove the protective container or unwrap the protective cloth from the xenon lamp. Warning: Ensure that you wear protective clothing, a full face shield and protective gloves. Tip: Write down the serial number of the lamp.
  • Page 37 4. Lamp & Lamp House Image 4-18 Anode socket installation 7. Reinstall the UV blocker assembly as illustrated. Make sure that the xenon lamp is properly supported by the lamp supporting mechanism in the centre of the UV blocker. Use the opening at the side of the Lamp House to guide the supporting pin of the xenon lamp into the anode supporting mechanism.
  • Page 38 4. Lamp & Lamp House 2,5 Nm Image 4-21 Fasten cathode side 10.Check the cathode connection inside the Lamp House. Use a 17 mm open-end wrench to hold the first nut while fastening the second nut on the rod with a torque of 9 Nm (6,64 lbf*ft) using a torque wrench with 17 mm hexagon socket. Ensure that there is a flat washer (reference 3) between the lock nut and the wire lug.

  • Page 39: Installation Of The Lamp House

    4. Lamp & Lamp House Image 4-23 Close side cover AUTION The “LAMP INFO” parameters MUST be updated after each installation of a xenon lamp inside the lamp house. Neglecting this update will result in poor performance and short life time of the xenon lamp. See procedure “Resetting the lamp parameters”.

  • Page 40: Resetting The Lamp Parameters

    4. Lamp & Lamp House Image 4-24 Mount lamp house 4. Push the lamp house forward until it slides fully into the projector. 5. Secure the correct position of the lamp house by tightening all three spring lock screws as illustrated. Image 4-25 Secure lamp house 6.

  • Page 41: Realignment Of The Lamp In Its Reflector

    4. Lamp & Lamp House The software will validate the selected article number (7). 5. Fill out the serial number of the lamp (8). 6. Click Reset (9). Image 4-26 Reset lamp info AUTION For more information about using the Communicator Touch Panel consult the user’s guide of the Communicator Touch Panel.
  • Page 42 4. Lamp & Lamp House 4. Set the “Light output mode” in normal mode and the “Lamp Dimming” on maximum (255). Note: This window on the Communicator touch panel shows in the upper left corner the measured value of the built-in light sensor of the projector.

  • Page 43: Lenses & Lens Holder

    • Scheimpflug adjustment Available lenses Which lenses are available for my projector? The table below is subject to changes and was last updated on 01/06/2012. Consult my.barco.com for the most recent information about available lenses. Product Number Type Zoom range...

  • Page 44: Lens Selection

    2. Login on my.barco.com. If you are not yet registered click on Sign up for my.barco.com and follow the instructions. With the created login and password, it is possible to enter the my.barco.com. When your login is correct, the my.barco.com start page is displayed.

  • Page 45: Lens Removal

    5. Lenses & lens holder The lens calculator (see screenshot, image 5-10) will be displayed. The lens calculator allows you to have an overview of which lenses are suitable for your specific projector setup. Just make your selection of parameters and all possible configurations are displayed. Image 5-10 Digital cinema lens calculator Due to production tolerances the real distances can differ by 2% from the calculated values.

  • Page 46: Lens Installation

    5. Lenses & lens holder Image 5-11 2. Gently pull the lens out of the lens holder. Image 5-12 Remove lens It’s recommended to place the Lens caps of the original Lens packaging, back on both sides of the removed Lens to protect the optics of the Lens.
  • Page 47 5. Lenses & lens holder Image 5-13 Lens holder lock Power connector lens Alignment pin 4. Ensure that the lens holder stands in the On-Axis position (horizontal and vertical mid position). Note: The lens holder is placed default in the On-Axis position at factory. 5.

  • Page 48: Lens Shift, Zoom & Focus

    5. Lenses & lens holder Lens shift, zoom & focus Motorized lens adjustment The DP2K C-series projector is equipped with a motorized lens shift functionality and a motorized zoom & focus functionality. Maximum shift range The lens can be shifted with respect to the DMD which result in a shifted image on the screen (Off-Axis). A 100% shift means that the centre point of the projected image is shifted by half the screen size.

  • Page 49: How To Adjust

    5. Lenses & lens holder (Scheimpflug) Image 5-18 Scheimpflug principle Scheimpflug principle The "plane of sharp focus" can be changed so that any plane can be brought into sharp focus. When the DMD plane and lens plane are parallel, the plane of sharp focus will also be parallel to these two planes. If, however, the lens plane is tilted with respect to the DMD plane, the plane of sharp focus will also be tilted according to geometrical and optical properties.
  • Page 50 5. Lenses & lens holder Image 5-20 2. Loosen the lock nuts (a, b, c and d). See image 5-19. 3. Loosen the 4 set screws (A, B, C and D) by 1 cm. See image 5-19. 4. Fully loosen lock nut 4. See image 5-19. 5.
  • Page 51 5. Lenses & lens holder Image 5-22 Left bottom focusing 7. Sharpen bottom right corner of the screen by adjusting nut 2. Image 5-23 Right bottom focusing 8. Sharpen top right corner of the screen by adjusting nut 3 R5905050 DP2K C-SERIES 10/07/2012...
  • Page 52 5. Lenses & lens holder Image 5-24 Corner focusing 9. Repeat from step 6 until the projected focus pattern is as sharp as possible in the center, left, right, top and bottom of the screen. How to fix the Scheimpflug Start the fixation as follows (steps must be followed strictly) : 1.

  • Page 53: Input & Communication

    6. Input & communication 6. INPUT & COMMUNICATION Overview • Introduction • Local keypad of the DP2K C-series projector • Communication ports of the DP2K C-series projector • Source input ports of the DP2K C-series projector • LED indications on the Integrated Cinema Processor module Introduction General The input &...

  • Page 54: Local Keypad Of The Dp2K C-Series Projector

    6. Input & communication Local keypad of the DP2K C-series projector Identification of the keys Image 6-2 Local keypad Marker area for macro name Numeric keyboard Standby key Dowser open/close switch Test pattern toggle switch Lens shift up/down, left/right Lens focus Lens zoom Numeric keys All the numeric keys (2) of the local keypad have a blue backlight during normal operation.

  • Page 55: Communication Ports Of The Dp2K C-Series Projector

    6. Input & communication Communication ports of the DP2K C-series projector Location of the communication ports STAT STAT STAT STAT CINEMA CONT POWER SMPTE 292/424 IN SYNC OK SYNC OK RS232 IN 3D INTERFACE PERIPHERAL PORT 10 / 100 / 1000 BASE-T DVI INPUT GENERAL PURPOSE IN/OUT DVI A...

  • Page 56: Source Input Ports Of The Dp2K C-Series Projector

    6. Input & communication Can be used to connect external 3D devices to the projector. All signals necessary for 3D projection can be provided via this con- nector. PERIPHERAL PORT For future use. Source input ports of the DP2K C-series projector Location of the source input ports STAT STAT...

  • Page 57: Led Indications On The Integrated Cinema Processor Module

    6. Input & communication Input Source Vertical rate Scan type Color space Sampling Color depth standard Single DVI VESA (640x480) 72 Progressive 4:4:4 8 bit Single DVI VESA (800x600) 60 Progressive 4:4:4 8 bit Single DVI VESA (800x600) 72 Progressive 4:4:4 8 bit Progressive...
  • Page 58 6. Input & communication ALTERNATIVE port selection. When on, LED 6 will be out. USB, for future use. R5905050 DP2K C-SERIES 10/07/2012...

  • Page 59: Communicator Touch Panel

    7. Communicator touch panel 7. COMMUNICATOR TOUCH PANEL Overview • Introduction • Installing the touch panel interface • Reposition the touch panel interface Introduction Communicator Touch Panel for digital cinema projectors The Communicator Touch Panel is designed for multi-user command and control, the Communicator enables users to learn quickly and operate efficiently - using an elegant and flexible touch panel interface.

  • Page 60: Installing The Touch Panel Interface

    7. Communicator touch panel Touch screen Communication panel Knob to operate central swivel clamp Base of swivel arm Power input 12 VDC, 1.5A RS232 port (sub-D) Ethernet port (RJ45) AUTION For more information about the use of the Communicator Touch Panel, consult its user guide. Installing the touch panel interface Necessary tools •...

  • Page 61: Reposition The Touch Panel Interface

    7. Communicator touch panel 3. Place the touch panel interface upon the mounting plate of the swivel arm and fasten the two wing nuts (W) as illustrated. Image 7-5 Mount touch panel 4. Connect the circular plug of the multi cable with the circular socket at the rear side of the DP2K C-series projector. Image 7-6 Connections 5.
  • Page 62 7. Communicator touch panel Image 7-8 3. Move the touch panel interface into the desired position. 4. Fasten the central swivel clamp by turning the big black knob clockwise. AUTION Never release the central swivel lock without supporting the Touch Panel interface. R5905050 DP2K C-SERIES 10/07/2012...

  • Page 63: Starting Up

    8. Starting up 8. STARTING UP About this chapter This chapter contains the switch ON and switch OFF procedures of the DP2K C-series projector. These procedures enumerate all the important points which have to be checked prior to switching ON the projector. This is to ensure a safe start up of the projector. Overview •...
  • Page 64 8. Starting up R5905050 DP2K C-SERIES 10/07/2012...

  • Page 65: Projector Registration

    Overview The current projector is DCI compliant and should be registered by Barco. Therefore, the digital certificate inside the projector will be used to secure encryption key communication between the projector and the rest of the theatre system (server and theatre man- agement system).

  • Page 66: Registration Of New Projector

    The procedure below gives an overview of all possible steps which can be displayed. How to register 1. Go to Barco’s Partnerzone on https://my.barco.com. 2. Login into the partnerzone. If you are not yet registered, click on Sign in here and follow the instructions. With the created login and password, it is possible to enter the partnerzone where you can upload the certificate.
  • Page 67 9. Projector registration Image 9-3 Lenses: click on the drop down box and select the lens of the projector when a M25 lens or select Other lens when no M25 lens is used. When other lens is selected, an extra input field appears to fill out the lens type. Anamorphic lens: check when an anamorphic lens is available.
  • Page 68 9. Projector registration If the location is not in the list, click Add new and continue to next step. 7. Fill out all fields with an asterisk for Location, Contact person and Support contact. Click Next >>. Image 9-5 Add new location The new location is added to the list of locations and is selected.
  • Page 69 9. Projector registration Image 9-7 Add new installer The new installer is added to the list of installers and is selected. Click Next >> to continue to next step. The owner input form appears. 10.If the owner is in the list, select the owner and click Next >> to finalize the registration. If the owner is not in the list, click Add new and continue with next step.
  • Page 70 9. Projector registration Image 9-9 Add new owner The new owner is added to the list of owners and is selected. Click Next >> to finalize the registration. The registration is completed. An E-mail will be sent to the person who is logged in. R5905050 DP2K C-SERIES 10/07/2012...

  • Page 71: Update Registration Of An Existing Projector

    How to update 1. First get a new certificate file. See "Download the certificate file", page 59. 2. Go to Barco’s Partnerzone on https://secure.barco.com/digitalcinema/. 3. Login into the partnerzone. Click Register DC projector and select Update DC projector.
  • Page 72 9. Projector registration The update page is displayed with your registered projectors. Image 9-11 Select projector to update 4. Select the projector for which the registration must be updated. The installation address is displayed in Selection Click >> Next to continue. 5.

  • Page 73: Removal And Installation Of Projector Covers

    10. Removal and installation of projector covers 10. REMOVAL AND INSTALLATION OF PROJECTOR COVERS About this chapter Most maintenance and servicing procedures demand removing one or more of the projector covers to gain access to the parts to maintain or to service. To avoid redundancy, all procedures about cover removing or installing are grouped together in this chapter. The maintenance and servicing procedures also refer to this chapter if required.

  • Page 74: Removal Of The Input Cover

    10. Removal and installation of projector covers 2. Remove the lamp cover from the projector doing the following: a) gently pull out the left bottom corner (A) of the lamp cover, b) then gently pull out the left top corner (B) of the lamp cover, c) then move the lamp cover away from the projector (C).

  • Page 75: Removal Of The

    10. Removal and installation of projector covers Image 10-4 Remove input cover 10.3 Removal of the front cover The input cover and the lens have to be removed before removing the front cover. See procedures "Removal of the input cover", page 68, and "Lens removal", page 39. Necessary tools Flat screw driver How to remove the front cover of the projector...

  • Page 76: Removal Of The Side Cover

    10. Removal and installation of projector covers Image 10-6 Remove front cover 10.4 Removal of the side cover Necessary tools Flat screw driver. How to remove the side cover of the projector? 1. Release the captive screw at the middle bottom of the side cover, using a flat screw driver. Image 10-7 2.

  • Page 77: Removal Of The Top Cover

    10. Removal and installation of projector covers How to remove the rear cover from the projector? 1. Release the two captive screws at the bottom corners of the rear cover, using a flat screw driver. Image 10-9 Release rear cover 2.

  • Page 78: Open The Sealed Compartment

    10. Removal and installation of projector covers Image 10-11 Top cover removal 2. Left up the top cover and take it off. Image 10-12 Top cover removal 10.7 Open the sealed compartment This procedure assumes that the left side cover of the projector is already removed. R5905050 DP2K C-SERIES 10/07/2012...

  • Page 79: Close The Sealed Compartment

    10. Removal and installation of projector covers Necessary tools 3 mm Allen wrench. How to open the sealed compartment of the Light Processor Unit? 1. Release the three hexagon head cap screws as illustrated. Use for that a 3 mm Allen wrench. Note: A washer is mounted between the plate and the screw head.

  • Page 80: Installation Of The Top Cover

    10. Removal and installation of projector covers Image 10-16 10.9 Installation of the top cover Necessary tools Allen key 3 mm How to install the top cover of the projector? 1. Place the top cover on the projector so that both holes matches the adjustment studs on top of the projector. Image 10-17 Mount top cover 2.

  • Page 81: Installation Of The Rear Cover

    10. Removal and installation of projector covers Image 10-18 Fixate top cover 10.10 Installation of the rear cover Necessary tools Flat screwdriver. How to install the rear cover of the projector? 1. Install the rear cover of the projector doing the following: a) Bring the rear cover towards it final position, b) then gently push the locking studs of the top corners into their receivers Image 10-19...

  • Page 82: Installation Of The Side Cover

    10. Removal and installation of projector covers Image 10-20 Fasten rear housing 10.11 Installation of the side cover Necessary tools Flat screw driver. How to install the side cover of the projector? 1. Check if the bottom and top filters are present. 2.

  • Page 83: Installation Of The Input Cover

    10. Removal and installation of projector covers Necessary tools Flat screw driver. How to install the front cover of the projector? 1. Check if the front filter is present. 2. Ensure that no lens is mounted and that the input cover is not installed. 3.
  • Page 84 10. Removal and installation of projector covers Image 10-25 Install input cover 2. Secure the input cover by locking the two captive screws at the left side of the input cover. Image 10-26 Fasten input cover R5905050 DP2K C-SERIES 10/07/2012...

  • Page 85: Maintenance

    11. Maintenance 11. MAINTENANCE About this chapter This chapter describes how to remove the dust filters Overview • Removing the front dust filter • Clean the dust filter on the bottom side • Clean the dust filter on the top side •...
  • Page 86 11. Maintenance Image 11-1 Dust filter access 3. Pull the small handle a little backwards and then to the front of the projector until the filter frame is released. 4. Slide the filter to the left. Image 11-2 Dust filter removal Clean the dust filter 1.

  • Page 87: Clean The Dust Filter On The Bottom Side

    11. Maintenance 11.2 Clean the dust filter on the bottom side Only for a DP2K-15C and a DP2K-20C projector. Remove the dust filter 1. Remove the side cover, see "Removal of the side cover", page 70. 2. Release the dust filter by pushing the handle a little bit downwards. Image 11-3 Bottom dust filter 3.

  • Page 88: Cleaning The Lens

    11. Maintenance Image 11-4 Top dust filter Clean the dust filter 1. Remove most contamination with a vacuum cleaner in an other room or outside. 2. Blow remaining dust away with compressed air in an other room or outside. Mount the dust filter 1.

  • Page 89: Cleaning The Exterior Of The Projector

    11. Maintenance 2. Wipe lenses in a one single direction. Warning: Do not wipe back and forwards across the lens surface as this tends to grind dirt into the coating. 3. Do not leave the cleaning cloth in either an open room or lab coat pocket, as doing so can contaminate the cloth. 4.

  • Page 90: Cleaning The Uv Blocker Of The Lamp House

    11. Maintenance If you cannot see the level , remove the top cover and shine with a torch on the filler cap while looking through the small window. Image 11-6 Filler cap 11.7 Cleaning the UV blocker of the Lamp House When cleaning the UV blocker? Only clean the UV blocker of the Lamp House in case it is really necessary.

  • Page 91: Authorization To Clear Security Warning On The Projector

    11. Maintenance 11.8 Authorization to clear security warning on the projector When is an authorization required to clear the security warning? If a module has been removed or if the sealed compartment has been opened, an authorization will be required to clear the security warning.
  • Page 92 11. Maintenance R5905050 DP2K C-SERIES 10/07/2012...

  • Page 93: Convergence

    12. Convergence 12. CONVERGENCE About this chapter This chapter describes how to prepare the projector for convergence adjustment and how to adjust the convergence. Overview • Convergence controls • Preparing the convergence adjustment • Red on Blue convergence • Green on Blue convergence 12.1 Convergence controls Extended control knobs As the DMD of the blue channel is not accessible in the projector, the image of this DMD will be taken as reference.
  • Page 94 12. Convergence Image 12-2 Convergence knobs on a DP2K-12C Red channel, knob number 1 Red channel, knob number 2 Red channel, knob number 3 Green channel, knob number 4 Green channel, knob number 5 Green channel, knob number 6 R5905050 DP2K C-SERIES 10/07/2012...

  • Page 95: Preparing The Convergence Adjustment

    12. Convergence Convergence test pattern Image 12-3 Convergence test pattern The test pattern illustrated above is specially designed for convergence purposes. The test pattern has three red arrows numbered from 1 to 3 and three green arrows numbered from 4 to 6. These numbers and colors correspond with the numbers and colors of the extended control knobs.

  • Page 96: Red On Blue Convergence

    12. Convergence a) Loosen both screws (reference 1 and 2). b) Slide the plate forwards until all hooks at both sides of the plate become free. c) Take off the plate. Image 12-4 Convergence cover plate 4. Reinstall the lens and start up the projector. 5.

  • Page 97: Green On Blue Convergence

    12. Convergence Image 12-6 Clockwise turning will move line downwards. 2. Slightly turn the red colored control knob number 2 until the red pattern in the lower left of the projected image converges with the blue pattern. Image 12-7 Clockwise turning will move line upwards. 3.
  • Page 98 12. Convergence Necessary tools No tools. How to converge 1. Slightly turn the green colored control knob number 4 until the green pattern in the center of the projected image converges with the blue pattern. Note that a turn of a few degrees corresponds with one full pixel. Note: When start turning the knob, a little resistance can be felt.

  • Page 99: Specifications

    About this chapter This chapter gives an overview of the specification of the projector as well as the dimensions, the center of gravity and the dimensions of the optional pedestal. 13.1 Specifications of a DP2K-12C projector Overview Digital MicroMirror Device™...

  • Page 100: Specifications Of A Dp2K-20C Projector

    13. Specifications 14,500 lumens Light Output Screen size Up to 15m / 49ft wide (screen gain 1.4 @ 14 ftl) Contrast ratio 2,000:1 Digital Video Inputs 2 x SMPTE 292M inputs 2 x DVI input both selectable as single and dual link Prime Lenses 1.2 - 1.8 1.4 - 2.05...

  • Page 101: Dimensions Of The Dp2K C-Series Projector

    13. Specifications Power Requirements 220V Dimensions 558(H) x 694(W) x 1034(D) mm 22.0(H) x 27.3(W) x 40.7(D) inch NB.: min. 5 cm of air inlet spacing required at the bottom of projector Weight 102kg (225lbs) Ambient temperature 35°C / 95°F Max. Options ACS-2048 3D add-ons...

  • Page 102: Center Of Gravity Of The Dp2K C-Series Projector

    13. Specifications Image 13-1 Dimensions 13.5 Center of gravity of the DP2K C-series projector Center of gravity Dimensions are given in mm R5905050 DP2K C-SERIES 10/07/2012...

  • Page 103: Dimensions Of The Universal Pedestal

    13. Specifications Image 13-2 Center of gravity 13.6 Dimensions of the universal pedestal Dimensions 876,3 Image 13-3 Dimensions given in millimeters. R5905050 DP2K C-SERIES 10/07/2012...
  • Page 104 13. Specifications R5905050 DP2K C-SERIES 10/07/2012...

  • Page 105: Pin Configurations

    A. Pin configurations A. PIN CONFIGURATIONS Overview • About General Purpose Inputs & Outputs (GPIO) • Pin configurations of the communication ports • Pin configurations of the inputs A.1 About General Purpose Inputs & Outputs (GPIO) General Purpose inputs Eight (8) opto-isolated general purpose inputs are available. These inputs are used to trigger the execution of macro files. For more explanation about the association of a macro to a GPI, consult the user guide of the Communicator touch panel.

  • Page 106: Pin Configurations Of The Communication Ports

    A. Pin configurations • Generate Falling Edge – generate a falling edge on the external GPO port if the present state of the output is high. If the present state of the external GPO is low, no edge will be generated. •...

  • Page 107: Pin Configurations Of The Inputs

    A. Pin configurations General Purpose In/Out GPOUT 8 P GPOUT 8 N reserved reserved reserved reserved reserved Ethernet port 10/100 Base-T — RJ45 port 1000 Base-T — RJ45 port Pair Color Description Description white/green TXD+ TX0+ green TXD- TX0- white/orange RXD+ RX0+ —...
  • Page 108 A. Pin configurations R5905050 DP2K C-SERIES 10/07/2012...

  • Page 109: Index

    Index INDEX General Purpose I/O GPIO Authorization Security warning Clear Available Lenses Important safety instructions Types Initial inspection INLET/OUTLET Fixation accessories Input Input & communication 47–51 Center of gravity Communication ports Certificate file Introduction Download LED indications ICT Clean Local keypad UV blocker Source input ports Clean dust filter...
  • Page 110 Physical installation Servicing Positioning Scheimpflug Pin configuration 100–101 Shift Communication ports Source input ports Inputs Specifications 93–94 Pin configurations DP2K-12C Position DP2K-15C Touch panel DP2K-20C Positioning Start up Power 18–19 Switching OFF Electronics Switching ON Use of UPS Projector registration 59–60, 65...
  • Page 111 Revision Sheet Barco nv Entertainment Division/Documentation Noordlaan 5, B-8520 Kuurne Phone: +32 56.36.82.11, Fax: +32 56.36.88.24 Support: www.Barco.com/esupport, Web: www.barco.com From: Date: Please correct the following points in this documentation (R5905050/04): page wrong correct R5905050 DP2K C- 10/07/2012 SERIES...
